Carrier SmartVu Control Manual page 137

INPUTS - Inputs Status
Name Range
1 STAR_AUX OPEN_CLOSE
2 RUN_AUX OPEN_CLOSE
3 DMP_FC NO_YES
4 DMP_FO NO_YES
5 DMP_ACT -
6 blank -
7 HGBP_FC NO_YES
8 HGBP_FO NO_YES
9 HGBP_ACT -
10 blank -
11 HP_SW OPEN_CLOSE
12 REM_CON OPEN_CLOSE
13 E_STOP OPEN_CLOSE
14 ICE_CON OPEN_CLOSE
15 REM_LOCK OPEN_CLOSE
16 SAFETY OPEN_CLOSE
17 STARTFLT OPEN_CLOSE
18 FS_LOCK OPEN_CLOSE
19 GV1_OHMS -
20 GV1_ACT -
21 GV2_ACT -
22 VFD_ACT -
23 DIFF_ACT -
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
Default Unit
OPEN -
OPEN -
NO -
NO -
0 -
- -
NO -
NO -
0 -
- -
OPEN -
OPEN -
OPEN -
OPEN -
OPEN -
OPEN -
OPEN -
OPEN -
0 -
0 %
0 %
0 %
0 %
REVISION DATE
2.3 Dec 4, 2020
Displayed text*
Compressor Start Contact
Compressor Run Contact
ECO DMP VLV Full Close
ECO DMP VLV Full Open
ECO DMP VLV Status
Cl=0,Inter=1,Op=2,Fail=3
EC/HG VLV Fully Close
EC/HG VLV Fully Open
EC/HG VLV Status
Cl=0,Inter=1,Op=2,Fail=3
High Pressure Switch
Remote Start/Stop
Emergency Stop Contact
Ice Build Contact
Chiller Lockout
Spare Safety Input
Starter Fault Feedback
Fire Security Interlock
Guide Vane 1 Actual Ohms
Guide Vane 1 Actual Pos
Guide Vane 2 Actual Pos
Actual VFD Speed Per
Diffuser Actual Pos
PAGE
137 OF 168
137
