Carrier SmartVu Control Manual page 131

Maintenance Menu
Trending
Quick Calibration
System
Configuration
*Depends on the selected language (English by default).
GENUNIT - General Parameters
Name Range
1 ctl_mode 0 to 3
2 blank -
3 blank -
4 cm_stas1 -
5 statstop STOP_START
6 CHIL_S_S DSABLE_ENABLE
7 CHIL_OCC NO_YES
8 HC_SEL COOL_HEAT
9 CTRL_PNT -12.22 to 71.11
10 to 160
10 reset -
11 setpoint -
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
Default Unit
0 -
- -
- -
0 -
STOP -
DSABLE -
NO -
COOL -
°C
-12.22
10 °F
0.00 ^C
0 ^F
°C
-17.78
0
REVISION DATE
2.3 Dec 4, 2020
USER
ALL
SERVICE
USER
Displayed text*
Control Mode
Local=0, Network=1
Remote=2, Local Sched=3
Compressor1 Run Status
Deter Start Stop Command
Network:Cmd Start/Stop
Network:Cmd Occupied
Cooling/Heating Select
Control Point
Control Point Reset
Actual Setpoint
PAGE
131 OF 168
MAINTAIN
QCK_CAL
SYSCONF
131
