Revision History
Revision Date (yyyy.mm.dd) Author
0.1 2017.03.17
1.0 2017.09.11
1.1 2018.01.08
1.2 2018.06.25
1.3 2018.08.21
1.4 2018.10.15
1.5 2018.11.27
1.6 2019.01.23
1.7 2019.05.29
1.8 2020.01.07
1.9 2020.03.17
Copyright © 2017 congatec GmbH
Changes
BEU • Preliminary release
BEU • Minor improvements throughout the document
• Updated image of conga-PA5 on title page
• Added LVDS, backlight, and new USB cable in section 1.2.3 "Optional Cables"
• Changed SPI flash size to 8 MB in section 2 "Feature Summary"
•
Included power consumption measurements in section 2.5 "Power Consumption" and 2.6 "Supply Voltage Battery Power"
• Added caution about correct orientation of the cooling solutions and updated images in section 4 "Cooling Solution"
•
Changed connectors in section 5.4.3 "USB 2.0 Header", 5.7.2 "LVDS Header", and 5.7.2.1 "Backlight Power Header"
• Added note about maximum current draw in section 5.7.2 "LVDS Header"
• Changed fuse limit to 500 mA in section 6.1.2 "I2C and Watchdog" and 6.1.3 "GPIOs"
• Updated connectors in section 7 "Mechanical Drawing"
• Included information in section 8 "BIOS Setup Description"
BEU • Updated supported OS in section 2.2 "Supported Operating Systems"
• Added caution about maximum cable length of USB 2.0 devices in section 5.3 "USB Connectors"
• Updated security features in table 6 "Feature Summary" and section 6.9 "Security Features"
•
BEU Added errata as a document to read in the preface section
• Updated "Electrostatic Sensitive Device" information on page 3
• Updated section 5.1.3 "USB Type-C™ Port"
• Included information about Wake-on-LAN support in section 5.4 "Gigabit Ethernet Ports"
• Updated section 5.7 "UART Headers"
BEU • Updated information throughout the document
•
BEU Corrected TPM in table 6 "Feature Summary" and section 6.9 "Security Features"
• Added borehole versions of heatspreaders to section 1.2.2 "Optional Accesories" and 4 "Cooling Solution"
• Added possible mating connectors
•
BEU Added a new commercial variant to table 1 and table 8
• Added S3 and S5 power consumption values to table 8
•
Added more cautions and information about correct orientation of the cooling solutions in section 4 "Cooling Solution"
• Added information about termination in table 5 and section 5.7 "UART Headers"
• Added new section 5.8 "MIPI CSI-2 (Camera)"
•
BEU Added note to the USB 2.0 adapter cable (14000210) in table 5
• Added note to use ODD pins for single channel LVDS panel in section 5.6.2 "LVDS/eDP Header"
BEU • Updated note in section 4 "Cooling Solutions"
•
Added power consumption values for new variant 048122 and corrcted S3 and S5 in table 8
BEU • Corrected cable length of item 14000147 in table 5
• Updated section 4 "Cooling Solutions"
•
Added reference to BIOS Setup Description application note in section 8 "BIOS Setup Description"
• Updated section 8.3 "Updating the BIOS"
•
Updated supported flash device in section 8.4 "Support Flash Devices"
• Updated section 9 "Industry Specifications"
BEU • Updated accessories in tables 3, 4, and 5 and combined them under section 1.2.3 "Optional accessories"
•
Removed table with cooling solutions from section 4 "Cooling solutions" and linked to table 3 instead
