The power consumption values were recorded during the following system states:
Table 7 Measurement Description
System State Description
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak value Highest power spike during the measurement of "S0: Maximum value".
This state shows the peak value over a short period of time (worst case
power consumption value).
S3 Suspend to RAM state.
S5 Soft-Off state
Note
1. The fan and SATA drives were powered externally.
2. All other peripherals except the LCD monitor were disconnected before measurement.
The tables below provide additional information about the power consumption data for each of the conga-PA5 variants offered. The values are
recorded at various operating modes.
Table 8 Power Consumption Values
Part Memory H.W BIOS
No. Size Rev. Rev.
048100 8 GB A.0 PA50R019
048101 4 GB A.0 PA50R019
048102 4 GB A.0 PA50R019
048120 8 GB A.0 PA50R019
048121 4 GB A.0 PA50R019
048122 4 GB B.1 PA50R140
048123 4 GB A.0 PA50R019
048110 8 GB A.0 PA50R019
048111 4 GB A.0 PA50R019
048112 4 GB A.0 PA50R019
Note
With fast input voltage rise time, the inrush current may exceed the measured peak current.
Copyright © 2017 congatec GmbH
OS
(64-bit) Variant
Windows ® 10 Atom ® x7-E3950
Windows ® 10 Atom ® x5-E3940
Windows 10 Atom x5-E3930
® ®
Windows 10 Pentium N4200
® ®
Windows 10 Celeron N3350
® ®
Windows 10
® Celeron ® J3455
Windows ® 10 Pentium ® N4200
Windows ® 10 Atom ® x7-E3950
Windows 10 Atom x5-E3940
® ®
Windows 10 Atom x5-E3930
® ®
Comment
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
CPU
Cores Base / Burst S0: Min S0: Max S0: Peak S3
Freq. (GHz)
4 1.6/2.0 0.16
4 1.6/1.8 0.28
2 1.3/1.8 0.14
4 1.1/2.5 0.28
2 1.1/2.4 0.29
4 1.5/2.3 0.19
4 1.1/2.5 0.16
4 1.6/2.0 0.16
4 1.6/1.8 0.28
2 1.3/1.8 0.14
PA50m112
Current (A) @ 12 V
S5
1.65 1.88 0.06 0.06
1.38 1.46 0.04 0.04
0.95 1.06 0.04 0.04
1.15 1.89 0.04 0.03
1.18 1.85 0.04 0.04
1.43 1.79 0.03 0.03
1.05 1.93 0.04 0.03
1.65 1.88 0.06 0.06
1.38 1.46 0.04 0.04
0.95 1.06 0.04 0.04
