24 CAM1_I2C_DAT Camera 1 Control Interface, DATA
25 GND
26 CAM1_CSI_CLK+ CSI2 Camera 1 Differential Clock+ (Strobe)
27 CAM1_CSI_CLK- CSI2 Camera 1 Differential Clock- (Strobe)
28 GND
29 CAM1_CSI_D0+ CSI2 Camera 1 Data Lane 0+
30 CAM1_CSI_D0- CSI2 Camera 1 Data Lane 0-
31 CAM1_RST# Camera 1 Reset (low active)
32 CAM1_CSI_D1+ N.C.
33 CAM1_CSI_D1- N.C.
34 GND
35 CAM0_GPIO GPIO for Camera 0
36 CAM1_GPIO GPIO for Camera 1
Connector Type
X1: 36 pins, 0.5mm pitch (Hirose FH12A Series); Possible Mating Connector: I-PEX FAW-1223-T1
Note
The MIPI interface fuse limits the power budget by 750 mA hold current.
