Selecting Keypad Transmission Format

The AYC-Ex5 has eight different keypad transmission formats to
select from. Follow the steps below to select the appropriate
keypad transmission format that you wish to use.
1) Enter Programming Mode.
2) Press "1" to enter.
• The Transmit LED will turn
Red.
3) Enter the appropriate option no. for the
keypad transmission format that you
wish to select (see table below).
If an incorrect option no. is entered the reader will return to
Transmit Mode and the keypad transmission format will
remain unchanged
4) Look on the next page for more information on keypad
transmission formats.
5) System returns to Transmit Mode.
• You will hear three beeps.
• The Program LED will turn off
• The Transmit LED will turn red
Note:
•
•
AYC-Ex5 family manual
Only one keypad transmission format can be active at any
one time.
When using the keypad transmission format "1 to 8 keys BCD,
Clock & Data" (Option 8) an additional input is required to
specify the number of keys in the PIN code.
Reader Functionality
Mode/Transmit
1
Mode/Transmit
Red
?
Mode/Transmit
Red
Door/Program
Green
Door/Program
Green
Door/Program
Page 18
