Controller Functionality
Auxiliary Mode 8
Auxiliary input function:
Auxiliary output activated by: Valid user code, Auxiliary code
E.g. In auxiliary mode 8, the controller can function as a two-door
controller and also provide indicator functionality control. The
auxiliary relay is connected to the lock on the second door. The
auxiliary setting defines the door open time for the second door.
The auxiliary input is used to control the Door indicator. If the
auxiliary input is open, the indicator will flash green; if the auxiliary
input is closed, the Door indicator will flash red.
Auxiliary Mode 9
Auxiliary input function:
Auxiliary output activated by: Valid user code, Auxiliary code
E.g. In auxiliary mode 9, the controller can function as a two-door
controller and also provide indicator functionality control. The
auxiliary relay is connected to the lock on the second door. The
auxiliary setting defines the door open time for the second door.
The auxiliary input is used to control the indicator. If the auxiliary
input is open the Door indicator will flash red; if the auxiliary input is
closed the Door indicator will flash green.
Page 49
Note:
This mode takes control of the Door indicator LED.
The indicator LED will not be lit when:
1. A valid code is entered
2. While in secure mode, when waiting for a secondary code.
Note:
This mode takes control of the Door indicator LED.
The indicator LED will not be lit when:
1. A valid code is entered
2. While in secure mode, when waiting for a secondary code.
Green LED control
Red LED control
