Wiring Instructions

4. Wiring Instructions
The unit is supplied with a 60-inch (1.5 meter) pigtail, having a 6-
conductor cable. To connect the unit to the controller, perform
the following:
Prepare the unit's cable by cutting the cable jacket back 1¼
inches and strip the wire ½ inch. Prepare the controller cable by
cutting the cable jacket back 1¼ inches and strip the wire ½ inch.
Splice the unit's pigtail wires to the corresponding controller wires
and cover each connection.
Refer to the wire color table below, and to the wiring diagrams
provided on the following pages.
Reader
5~16 VDC
Shield / Ground Shield / Ground Black
Data 1 / Clock
Data 0 / Data
LEDCTL
Tamper
If the tamper output is used, connect the purple wire to the
correct input on the controller when used as a reader, or to a
zone input of an intruder alarm system when used as a controller.
Trim and cover all unused conductors.
•
•
•
Page 11
Controller
5~16 VDC
C 1
C 2
AUX. IN
Tamper
Note:
The individual wires from the unit are color-coded according
the Wiegand standard.
When using a separate Power Supply for the Reader, this
Power Supply and that of the Controller must have a common
ground.
The Reader's cable shield wire should preferably be attached
to an earth ground, or a signal ground connection at the
panel, or power supply end of the cable. This configuration is
best for shielding the Reader cable from external interference
Color Functionality
Red +DC Input
Ground
White Communication
Green Communication
Brown LED Control / Auxiliary Input
Purple Tamper
