Auxiliary Input & Output; Door Alarms; Internal Case And Back Tamper - Rosslare AYC-Ex5 Instruction Manual

Changing from Bypass Mode to Normal Mode
See Changing the Normal / Bypass Code and Door Chime
Settings on page 40 to create/modify the Normal / Bypass code.
1) Enter the Normal / Bypass
code
• Mode LED will flash green
2) Press the "#" key to
confirm the mode ch
• Mode LED will turn green
6.3 Auxiliary Input & Output
For optimum usability in different applic
auxiliary input and output can be configured in ten different
modes of operation.
6.4

Door Alarms

Door alar ms can be gener
to a Door Position Switch. Either Door-Forced or Door-Ajar
conditions are supported, as well as, a configurable delay timer
for each alarm type. Only one Door-alarm is enabled at any one
time. Door alarms may activate auxiliary output and siren
depending on the auxiliary settings.
6.5

Internal Case and Back Tamper

In cas the unit is forcibly opened or it is remov e
tamper event is triggered. A tamper output opens sending a to
the connected Alarm system (purple wire) the event closes when
the tamper is closed (case is re-closed or re-attached to the wall).
