Auxiliary Mode 2
Auxiliary input function:
Auxiliary output activated by: Bell Button ( )
E.g. In auxiliary mode 2, the auxiliary relay can function as a
general purpose time switch that can be activated when the Bell
button ( ) is depressed. The auxiliary setting establishes for how
long the auxiliary relay is to be activated. The auxiliary input can
switch the mode of operation of the controller between normal
and secure mode. By connecting a switch timer or alarm system
output to the auxiliary input, the controller can be automatically
switched from normal mode (during office hours) to secure mode
(after office hours).
Auxiliary Mode 3
Auxiliary input function:
Auxiliary output activated by: Alarms
E.g. In auxiliary mode 3, the auxiliary output is activated if the
controller is tampered; that is, if the case is forcibly opened or
removed from the wall. The auxiliary input can switch the mode of
operation of the controller between normal and secure mode. By
connecting a switch timer or alarm system output to the auxiliary
input, the controller can be automatically switched from normal
mode (during office hours) to secure mode (after office hours).
AYC-Ex5 family manual
Controller Functionality
Toggles normal/secure modes
Toggles normal/secure modes
Page 46
