Controller Functionality; Normal, Secure, And Master Users - Rosslare AYC-Ex5 Instruction Manual

6.

Controller Functionality

The AYC-Ex5 series can function both as a reader and as a
controller. If the unit is connected to Rosslares' secure application
appurtenance, it functions as a controller indicated by two beeps
immediately after power-on reset.
The lock strike and Auxiliary outputs as well as the Request to Exit
input are not located on the AYC-Ex5 unit, eliminating the
possibility of unauthorized entry to the restricted area.
The following explains how the AYC-Ex5 series functions as a
controller.
6.1

Normal, Secure, and Master Users

The AYC-Ex5 accepts up to 500 users and provides entry via the
use of PIN codes and/or Proximity cards. Each user is provided
with two code memory slots, Memory Slot 1 (Primary Code) and
Memory Slot 2 (Secondary Code).
The pin code length has several options. The pin code length can
be a set number of 4, 5 or 6 digits or it can be a 4-8 digits option.
When choosing the 4-8 digit option, please note that you should
either enter zeros before the code, or press pound at the end (for
example if your code is 12345, enter either 00012345 or 12345#).
AYC-Ex5 family manual
Note:
•
Entering a code refers to either PIN or CARD depending on
the model you have.
Controller Functionality
Page 30
