This manual provides details about the Nios
Cyclone™ II Edition.Nios Development Board Cyclone II Edition
The table shows this document's revision history.
Date & Revision
May 2007, 1.3 ●
●
●
October 2006, 1.2 ●
●
June 2006, 1.1 ●
●
●
●
●
●
●
●
●
●
●
●
●
May 2005, 1.0 First publication.
For the most up-to-date information about Altera products, refer to the
following table.
Contact (1)
Technical support
Technical training

About this Manual

Description
Corrected Figure 1-1 and Figure 2-21.
Revised "How to Contact
Updated headers and footers.
Corrected statement: LEDs D0 - D7 turn on when driven
to 0, not 1.
Updated headers and footers.
Updated part numbers to RoHS compliant parts
Corrected D7 pin information in LED pin table
Removed pin labels from J19 figure
Added J19 pin table
Changed PROTO1 and PROTO2 figures to use board
net names
Added PROTO1 and PROTO2 pin tables
Corrected FPGA pin label for CON3 pin 9 in PMC
Connector pin table
Added new pin AE15 to PMC Connector pin table
Added U69 pin table
Corrected factory config button figure
Added pin and device information and corrected net
name for U3 Starting Configuration step 3
Improved clock circuitry figure
Added clock signal pin tables
