Board Components
2–28
Nios Development Board Cyclone II Edition
Table 2–15. PMC Connector Pin Table (Continued)
FPGA Pin JH1 & JH2 Pin
L24 59
L25 58
M19 55
M22 54
M23 53
R24 51
U22 49
U25 49
W21 48
W23 48
W24 47
W25 46
Y21 45
Y23 46
Y24 31
Y25 32
Y26 29
AA23 29
AA24 28
AA25 28
AA26 27
AB23 26
AB24 23
AB25 23
AB26 22
AC23 22
AC25 21
AC26 20
AD24 19
AD25 20
R20 52
T22 43
T24 32
T25 26
Reference Manual
Connector Board Net Name
JH1 pmc_ad2
JH1 pmc_ad3
JH1 pmc_ad4
JH1 pmc_ad5
JH1 pmc_ad6
JH2 pmc_ad7
JH2 pmc_ad8
JH1 pmc_ad9
JH2 pmc_ad10
JH1 pmc_ad11
JH1 pmc_ad12
JH2 pmc_ad13
JH2 pmc_ad14
JH1 pmc_ad15
JH2 pmc_ad16
JH1 pmc_ad17
JH2 pmc_ad18
JH1 pmc_ad19
JH2 pmc_ad20
JH1 pmc_ad21
JH1 pmc_ad22
JH2 pmc_ad23
JH2 pmc_ad24
JH1 pmc_ad25
JH2 pmc_ad26
JH1 pmc_ad27
JH1 pmc_ad28
JH2 pmc_ad29
JH2 pmc_ad30
JH1 pmc_ad31
JH1 pmc_be_n0
JH2 pmc_be_n1
JH2 pmc_be_n2
JH1 pmc_be_n3
