Individual LEDs
(D0 - D7)
Seven-Segment
LEDs (U8 & U9)
Altera Corporation
May 2007
This Nios development board provides eight individual LEDs connected
to the FPGA. Refer to
"Push-Button Switches (SW0 - SW3)" on page
D0 – D7 are connected to general purpose I/O pins on the FPGA as
shown in
Table
2–4. When a pin drives logic 0, the corresponding LED
turns on.
Table 2–4. LED Pin Table
LED
D0
AC10
D1
W11
D2
W12
D3
AE8
D4
AF8
D5
AE7
D6
AF7
D7
AA11
U8 and U9 connect to the FPGA, and each segment is individually
controlled by a general-purpose I/O pin. Refer to
drives logic 0, the corresponding U8 and U9 LED turns on. See
for pin-out details.
Figure 2–3. Dual Seven-Segment Display
f
e
Reference Manual
FPGA Pin
pld_led0
pld_led1
pld_led2
pld_led3
pld_led4
pld_led5
pld_led6
pld_led7
U8
U9
a
a
b
f
b
g
g
c
c
e
d
d
dp
dp
Nios Development Board Cyclone II Edition
Board Components
2–4.
Board Net Name
Figure
2–3. When a pin
Table 2–5
2–5
