Use Auto Scale to easily capture and see the detected Largest Event
applying automatic scaling of the amplitude of the trace in the vertical
axis.
Pulse Width is a non-editable value in Auto TDR but can be selected

from a given list in Manual and xTalk TDR.
Dual Trace Offset is a configurable offset parameter for the secondary

trace, with a range of -100 % to +100 %.
Note: If the loaded secondary trace offset = 0, then the primary and secondary
traces will overlap.
VOP allows you to change the velocity of propagation value for the

cable as defined in m/μsec (meters per microsecond), a ratio, or
percentage of the speed of light.
Current Trace (available only in Manual TDR)

allows you to turn on/off Live and Peak traces
and calculates the Differential trace. Select
one of the following:



Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set
Live turns Peak Hold off clearing
previously collected minimum/maximum
measurement values. This is the default.
Live and Peak turns Peak Hold on and
collects minimum/maximum
measurement values, displaying all
3 traces.
Peak Only turns Peak Hold on displaying
only Peak traces with no offset.
TDR
Continuous
255
