Multimeter Tests
Resistive Balance
Threshold Settings button opens a new page that allows you to set the

resistive balance thresholds.
Test Status displays the current state of measurement or an error

message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
4. Press
Resistive Balance Threshold Settings
The Threshold Settings page allows you to set the
Resistive Balance (
threshold is a programmable value you can use as an
on-screen indicator in each test when a measured
value is too high or too low.
Type is the threshold limit for each pair: either

Maximum or Minimum.
Enabled is a flag to use the current threshold:

either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
132
on a value to open a list box of options.
to confirm the value.
Threshold values. The
Ω)
on a value to open a list box of options or the alphanumeric
to confirm the value.
