SmartR™ Features
Pair Detective
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
Pair Detective Threshold Settings
The Threshold Settings page allows you to set the threshold parameters
for the tests below. Modifying these values will change what color is used
on a result and when a fault is identified, such as a short at 3.5 M ohms.
Foreign DC Voltage sets the maximum foreign DC

voltage value. Default is 4 V which is fine for POTS
and internet circuits; consider a lower value for
high-a speed DSL such as VDSL2.
POTS DC Voltage sets the minimum working

POTS DC voltage value.
POTS DC Current sets the minimum working

POTS DC current value.
Capacitive Balance sets the minimum capacitive

balance threshold as a percentage.
Good VF/AC Balance sets the good VF/AC balance threshold.

Marginal VF/ACBalance sets the marginal VF/AC balance threshold.

Isolation sets the isolation resistance threshold.

Type is a read-only field displaying the threshold limit: either Minimum

or Maximum.
Enabled is a read-only field and always Yes for all thresholds.

158
on a value to open a list box of options or the alphanumeric
to confirm the value.
