Threshold Settings button opens a new page that allows you to set the

capacitance balance threshold for the test.
Result displays a snapshot of the pass/fail status, Capacitance and

Length for each selected wire pair. Capacitive Balance is shown in %
when All Pairs is selected.
Test Status displays the current state of measurement or an error

message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
keys to scroll through.
4. Press
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set
Capacitance T/R or A/B to GND/E displays the capacitance value
from Tip or Ring to Ground, in nF/mi or km ranging from 10.0
to 500.0.
on a value to open a list box of options and use the navigation
to confirm the value.
