SmartR™ Features
Pair Detective



Result displays the distance to the most significant reflection, in text

and graphical measurements. The distance (Delta) value between
cursor and marker is also displayed at the top of the graph.
Test Status displays the current state of measurement or an error

message.
To select the parameter values in Portrait Mode:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view, select the options, or
increase/decrease values.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
Landscape Mode is the best way to use the TDR and allows you to

view the test results in landscape mode utilizing the full length of the
high resolution, color screen. Whether the keyboard is on the right or
left is dependent on your preferred Landscape Mode Settings
configured in Setup/Application Settings/General.
Landscape Mode generates the following function keys:


162
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the
Continuous page.
on a value to open a list box of options or the alphanumeric
to confirm the value.
Portrait Mode is used to change the screen orientation from
landscape to portrait.
Select Graph opens a new selection of function keys which allow
you to maneuver the graph. (Same as above.)
