Saving, Reading, And Managing Dsl/Ip Test Results; Saving Results - EXFO MaxTester 635G User Manual

16 Saving, Reading, and
Managing DSL/IP Test Results

Saving Results

You can save a snapshot of test results into a result file during or after
performing a DSL/IP test, with the MaxTester. Each Auto Test, Manual, and
Ethernet test includes an Upload/Save Result tab to do so. The tab allows
you to Upload & Save (see Upload Setup on page 37) your test results
using the following:
out-band upload method if not disabled and the test is stopped

existing in-band method if enabled, using the DSL or Ethernet

connection made during the test, and the test is running.
Or you can Save your results to an internal memory file or Export results to
an HTML, MHTML, or XML report using a USB key.
Alternately, when a test is completed or stopped and
you press
pops up. Selecting Yes displays the Upload/Save
Result screen where the following information can be
entered:
Identification Fields





Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set
, Confirm Save Results dialogue box
User Name/User ID display the values set up
in the Setup/Application
Settings/Identification tab. You can edit this
field using the editor screen.
Contractor Name allows you to enter the
name of a contractor used to perform the tests.
Test From/To display the values set up in the Setup/Application
Settings/Identification tab. You can edit this field using the
choices from the list box.
Job ID allows you to create/edit a unique identifier for the task.
405
