Recalculate button allows you to recalculate data rates after editing

the following Test Parameters:



Note: VDSL2-35b requires the VDSL2-35b Data Rate Prediction software option
and CQ Board Revision J or higher.

Information



To recalculate the DRP:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to increase/decrease the values.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
5. Press the up button to select the Recalculate button.
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set
SNR Margin is the signal-to-noise ratio margin measured on the
line.
Bits/Bin allows you to select the ADSL bandwidth bit rate.
Technology allows you to select a frequency band from a list of
possible technologies (subject to the Software Options enabled).
Reference Point (side) is either CO (default) or CPE. Set this value
based on where you connect the tester: for example, if the tester is
connected at the user side and performs a test toward the CO, set
the Reference Point to CPE.
Annex displays the mode: A or B.
Remote Noise Level ranges from -40 to -110 dBm/Hz (default) and
is configurable in profile *.cqcfg files. The noise level value is
dependent on the Reference Point.
on a value to open a list box of options or the alphanumeric
to confirm the value.
Copper Auto Tests
User Auto Test
