The following parameters are available only when the test setup is for
Ethernet.
WAN/LAN Link Speed is always set to Auto (GVXAA and GVXAB
models only).
Note: GVXAA and GVXAB models also support 1000 Mbit/s.
To configure the setup options:
1. Press the up/down arrows to select the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
5. If you make any changes to the parameter values, press the on-screen
function keys to save or cancel your input.
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set
DNS1 is the address of the primary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
DNS2 is the address of the secondary domain name server to be
used by the unit. If DNS is unavailable, enter 0.0.0.0.
WAN/LAN Link Speed is a choice between Auto (negotiated
during the link establishment), 100, or 10 Mbit/s.
WAN/LAN Connect Mode is Full- or Half-Duplex, when Link
Speed is set to 100, or 10 Mbit/s.
on a value to open a list box of options or the alphanumeric
to confirm the value.
Setting Up DSL/IP Tests
Test Configuration
335
