ClearCube A1010 User Manual page 67

• Windows 2000, Server 2003, and Windows XP
Operating System
Support • Linux®–ready
• PS/2 keyboard
Top Access Ports
• PS/2 mouse
• Parallel port (25-pin LPT)
• VGA port (DB-15 mini)
• Serial port (15-pin COM1)
• Two USB 2.0 ports
• 10/100 Ethernet
Back Panel Ports
• Two USB 2.0 ports
BIOS AMI BIOS
• Size: 10 inch (H) x 29.5 inches (L) x 1.75 inches (W)
Dimensions
• Weight: 13 pounds
Environment Stationary office, 0–35° C
Table 8. A3000 Chassis Specifications
Feature
• Hot-swappable modules
Connections
• 6U form factor, 10-slot chassis
• Fit 7 chassis (70 PC Blades) in a single 42U rack or cabinet
• Dual rear power connections
• 6U (10.5 inches high, standard 19-inch rack width)
Dimensions
• 17.0-inch (w) x 10.5-inch (h) x 29.75-inch (d)
• 100–240 VAC, 50/60 Hz
Power Input
• Power supplied to each individual blade slot
• 1500 W power required per power input (maximum)
• 5000 BTU heat generation per hour per full chassis (maximum)
• 12 Amps current required per power input (at 100 VAC) (maximum)
AC Input Fuse
Weight 38 pounds empty, 168 pounds with 10 blades
Environmental Rack mounted, 0–35º Celsius (C)
T15A, 250V (5x20 mm slow-acting 15 ampere fuse)
Description
• 55
