The following figure shows typical cabling configuration between an A3100 chassis with
A1410 blades and user ports (A1410 blades do not support the secondary Ethernet ports on
A3100 chassis).
A3100 Chassis with 10 A1410 Blades
PCoIP
PCoIP
. . . .
. . . .
PRI
SEC
PRI
SEC
BLADE 5
BLADE 6
External Data Sources
and Entities
Data
Network
Network Switch
User Ports and Peripherals
Figure 13. A3100 chassis cabling
Cable Requirements
• 23
