Powering a Chassis

As shown in
receptacles, one for each half of the chassis.
If only one power cord is connected to an A–Series chassis, only the side of the chassis that is
connected to power will supply power to blades. Only use AC power cords supplied with the
34 • Chassis and Blade Installation
Figure 22 and Figure 23
Power Supply for
Blades 6–10
Figure 22. A3100 chassis with two power receptacles
Power Supply for
Blades 6–10
Figure 23. A3000 chassis with two power receptacles
on this page, A–Series chassis have two power
Power Supply for
Blades 1–5
Power Supply for
Blades 1–5
