Chapter 3. Chassis and Blade Installation

Installing ClearCube products is a series of simple tasks that you can perform in a short
amount of time. The following instructions are intended for IT technicians who are familiar
with computer systems and familiar with configuring hardware. This chapter discusses the
following topics:
• "Tools for
• "Installing an A–Series
• "Installing a Blade in

Tools for Installation

You can perform all installation tasks with the following tools:
• #2 Phillips screwdriver—Required.
• 1/4–inch nut driver with magnetic tip—Optional. Suggested for removing and replacing
the self-tapping sheet metal screws located on the A3000 and A3100 chassis.
Installing an A–Series Chassis
Mount your A–Series chassis on a standard, 19-inch rack or cabinet to hold your A–Series
blades. The following list describes each A–Series chassis.
• A3100 chassis—Compatible with A1410 blades only. The following list details the
chassis components.
–
A–Series User's Guide
Installation" on this page
Chassis" on this page
Chassis" on page 39
Front Bezel—Shown in the following figure, the A3100 front bezel is compatible
with A3100 chassis and A1410 blades only.
25
