ClearCube A1010 User Manual page 41

3. For A3100 chassis only—Remove the front rack ears that are currently on the A3100
chassis.
4. Mount the chassis bracket to the chassis with four flathead screws included with your kit.
Repeat on the other side of the chassis.
Note: You can use the chassis and rack brackets on either side of your rack or cabinet; that
is, the brackets are not specific to either side of your enclosure.
Front Rack Ears Locking Latch
Main Bracket
Figure 15. Rack bracket for chassis rapid–mount kit
5. Determine the location and holes to use to mount the rack ears on the rack bracket. A
guide is provided with the chassis rapid–mount kit.
6. Insert the slider rack ears, as shown in
rack post.
7. Pull the rack bracket forward and insert the front rack ears into holes on the front side of
the front post, as shown in
8. Push forward on the ears until the locking latch, shown in
and locks into place. To ensure that the bracket is level, check that you placed the front
Spring
Finger Handle
Slider Ears Inserted
in Rear Post
Figure 16. Rack bracket attachment points
Figure 16
Slider
Figure 16 on this page, in the back side of the rear
Front Ears
Inserted in Front Post
on this page.
Figure 15
Installing an A–Series Chassis
Slider (Back)
Rack Ears
Flanges
on this page, snaps
• 29
