4. Using the hardware provided with your cabinet, attach the chassis mounting brackets to
the cabinet rails.
5. As shown in
the chassis and to the rack with the two 10-32 screws supplied in your shipment. Obtain a
cage nut to attach the strap to your cage. Ensure that the rack is properly grounded.
6. Supply power to the chassis.
a. Attach the AC power cords included with the chassis to both rear panel power
b. Connect the AC power cords to a surge-protected power source such as an
Note:
Ensure that all rooms or data centers in which you install PC blades are clean before you begin
installing blades. ClearCube recommends completing all additional chassis hardware
installation and preliminary network cabling for user ports before you begin installing any PC
blades.
Mounting a Chassis Rapid–Mount Kit
The chassis rapid–mount kit is compatible with most four-post racks and cabinets. To install a
chassis with the chassis rapid–mount kit, perform the following steps.
1. Ensure that you:
–
–
2. Unscrew the thumbscrew holding each pair of chassis and rack brackets together, and then
slide the brackets apart.
–
–
28 • Chassis and Blade Installation
Figure 14 on this page, attach the ground strap (included with the chassis) to
Figure 14. Chassis ground strap
connectors on the chassis.
uninterruptible power supply (UPS) or power strip. Use the cable retention clamps to
secure the power cables.
ClearCube products shipped to countries using 100–130-volt power systems
include power cords rated at 15 amperes. ClearCube products shipped to
countries using 208–240-volt power systems include power cords rated at 10
amperes. See "Safety
Install your chassis from the front of the rack or cabinet.
Begin installing chassis at the bottom of the rack or cabinet to provide support for
each chassis before it is securely mounted. This simplifies getting the chassis square
and level in the rack.
The bracket containing springs is the rack bracket and is installed on the rack.
The solid bracket is the chassis bracket, and it is screwed to the chassis.
g
Guidelines" on page x for more information.
Ground Strap
