The following figures show the A–Series blades and their major components.
Hard Drive Cables
Hard Drive
Hard Drive Cable
42 • Upgrading and Maintaining Blades and Components
Blade power supplies
Blade fans
Blade motherboards
Daughter cards, including V5120 Dual Host card and V5140 Quad Host card
Figure 27. Layout of A1410 major components
Figure 28. Layout of A1010 major components
Hard Drive
Memory
Top Cover
Memory
