Specifications for A3000 and A1010 Configurations
The following table details power and thermal specifications for various A3100 and A1410
configurations.
Units Per Rack
Chassis Max No Blades
Space (U)
1 10
2 20
3 30
4 40
5 50
6 60
7 70
1 10
2 20
3 30
4 40
5 50
6 60
7 70
1 10
2 20
3 30
4 40
5 50
6 60
7 70
1 10
2 20
3 30
4 40
5 50
6 60
7 70
NOTE: Power and current figures are per chassis. Each chassis has two separate IEC power inputs. Each input supplies power to five
blade slots in the chassis. For power and current figures per input, divide these numbers by 2.
When specifying uninterruptible power supplies (UPS), use the peak current draw to
determine the appropriate UPS.
• 1 chassis—3 kVA UPS
20 • Site Preparation and Network Planning
Table 4. A1010 Power and Cooling Requirements
Power Requirements
Rack Peak Power
kVa Watts (W)
6U 2.40 1,500
12U 4.80 3,000
18U 7.20 4,500
24U 9.60 6,000
30U 12.00 7,500
36U 14.40 9,000
42U 16.80 10,500
6U 2.88 1,500
12U 5.76 3,000
18U 8.64 4,500
24U 11.52 6,000
30U 14.40 7,500
36U 17.28 9,000
42U 20.16 10,500
6U 2.91 1,500
12U 5.82 3,000
18U 8.74 4,500
24U 11.65 6,000
30U 14.56 7,500
36U 17.47 9,000
42U 20.38 10,500
6U 2.88 1,500
12U 5.76 3,000
18U 8.64 4,500
24U 11.52 6,000
30U 14.40 7,500
36U 17.28 9,000
42U 20.16 10,500
Current Draw
Current (A) Generated Heat Load (Btu/hr.)
Low High Peak
100V
13.2 20.4 24
26.4 40.8 48
39.6 61.2 72
52.8 81.6 96
66.0 102.0 120
79.2 122.4 144
92.4 142.8 168
120V
7.14 12.66 24
14.28 25.32 48
21.42 37.98 72
28.56 50.64 96
35.7 63.3 120
42.84 75.96 144
49.98 88.62 168
208V
4.16 6.98 14
8.32 13.96 28
12.48 20.94 42
16.64 27.92 56
20.8 34.9 70
24.96 41.88 84
29.12 48.86 98
240V
3.66 5.86 12
7.32 11.72 24
10.98 17.58 36
14.64 23.44 48
18.3 29.3 60
21.96 35.16 72
25.62 41.02 84
Thermal
Min Max Peak
2,817 4,353 5,121
5,633 8,706 10,242
8,450 13,059 15,363
11,266 17,411 20,484
14,083 21,764 25,605
16,899 26,117 30,726
19,716 30,470 35,847
2,817 4,353 5,121
5,633 8,706 10,242
8,450 13,059 15,363
11,266 17,411 20,484
14,083 21,764 25,605
16,899 26,117 30,726
19,716 30,470 35,847
2,817 4,353 5,121
5,633 8,706 10,242
8,450 13,059 15,363
11,266 17,411 20,484
14,083 21,764 25,605
16,899 26,117 30,726
19,716 30,470 35,847
2,817 4,353 5,121
5,633 8,706 10,242
8,450 13,059 15,363
11,266 17,411 20,484
14,083 21,764 25,605
16,899 26,117 30,726
19,716 30,470 35,847
Required Cooling
Min Max
(tons) (tons)
0.2 0.4
0.5 0.9
0.7 1.3
0.9 1.7
1.2 2.1
1.4 2.6
1.6 3.0
0.2 0.4
0.5 0.9
0.7 1.3
0.9 1.7
1.2 2.1
1.4 2.6
1.6 3.0
0.2 0.4
0.5 0.9
0.7 1.3
0.9 1.7
1.2 2.1
1.4 2.6
1.6 3.0
0.2 0.4
0.5 0.9
0.7 1.3
0.9 1.7
1.2 2.1
1.4 2.6
1.6 3.0
