Figure 5
Each A1010 blade has a serial number. The serial number is also printed on a label adjacent to
the fans on the front of the blade, as shown in
The serial number can be useful if you need to identify a blade or a blade model. A1010 blade
serial numbers use the syntax:
ABNnnnnn
where ABN is the serial number prefix, and nnnnn is a five-digit number.
A–Series Chassis
The following sections describe the A3100 chassis with the expansion backplane and the
A3000 chassis.

A3100 Chassis and Expansion Backplane

The following list describes dimensions and features of the A3100 chassis.
• 6U high
6 • A–Series Architecture and Product Overview
on this page shows the A1010 rear panel
Hard Disk
Activity Indicator
Figure 5. A1010 back panel
Figure 3 on page 4.
Ethernet Port
USB Ports
Power Indicator
Power Button
Reset Button
