4. Enter the volume of the Clinician Bolus and
press to begin priming procedure. You may
stop the bolus at any time by pressing
5. The volume for the bolus will be in ml, mg or µg
depending on the settings of the existing
protocol entered for the infusion. To change
protocol data, press
menu. Then go to 'Modify Protocol Library' and
follow the steps until the relevant selection can
be made for ml, mg or µg.
6. The display screen will show a graph indicating
the bolus is being infused. The graphical bar
displays the amount of the bolus to be infused
(grey) and the amount infused (green).
NOTE: Once the bolus is completed, the display will change back to the menu.

NOTE: User can stop bolus at any time by pressing

Warning: Boluses will be infused up to the full volume that is requested unless
the user stops the bolus manually by pressing
volume infused is less than the specified Hour Limit for Volume (e.g. 4 Hr
Limit) at the beginning of a bolus and goes over the limit during the bolus.
To infuse a Clinician Activated Bolus during an infusion, perform the following steps:
During operation, press
1.
initiate the Clinician Bolus.
Enter relevant Code and press
2.
BodyGuard 545 Color Vision™ Directions For Use
.
until you return to the
and then press
.
EPIDURAL 10:00
Clinician Bolus
Dose
5
mL
(Maximum 20mL)
Press Key to Start
EPIDURAL 10:00
Clinician Bolus
Dose
5
mcg
(Maximum 40mcg)
Press Key to Start
EPIDURAL 10:00
Bolusing
███████████████████
Bolus Dose
Bolus Rate
████████████████████████
20 of 400 mmHg
.
. This is true even when the
to stop the current infusion and
4 - Operation
- 70% █
■
- 70% █
■
- 70% █
■
5 mL
2 mL/hr
