Proline Prosonic Flow 93C FOUNDATION Fieldbus
Block information,
execution time
VCRs
Output data
Endress+Hauser
Block
Resource Block
"Flow" Transducer Block
"Diagnosis" Transducer Block
Transducer Block "Service"
"Display" Transducer Block
"Totalizer" Transducer Block
Analog Input function block 1
Analog Input function block 2
Analog Input function block 3
Analog Input function block 4
Analog Input function block 5
Analog Input function block 6
Analog Input function block 7
Analog Input function block 8
Discrete Output Function Block (DO)
PID Function Block (PID)
Arithmetic Function Block (ARTH)
Input Selector Function Block (ISEL)
Signal Characterizer Function Block (CHAR)
Integrator Function Block (INTG)
VCRs (total 48)
Permanent Entries
Client VCRs
Server VCRs
Source VCRs
Sink VCRs
Subscriber VCRs
Publisher VCRs
Transducer Blocks / Analog Input Function Blocks
Block
"Flow" Transducer Block
"Totalizer" Transducer Block
Base index Execution time [ms]
400 –
2600 –
1600 –
1700 –
1800 –
1900 –
500 18
550 18
600 18
650 18
700 18
750 18
800 18
850 18
900 18
1000 25
1100 20
1150 20
1200 20
1250 18
Process variable
Average volume flow
Average sound velocity
Average flow velocity
Signal strength channel 1
Signal strength channel 2
totalizers1
totalizers2
Totalizer 3
Technical data
Functionality
Enhanced
Vendor specific
Vendor specific
Vendor specific
Vendor specific
Vendor specific
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Quantity
1
0
24
23
0
23
23
Channel parameter
(AI Block)
25
28
29
30
31
7
8
9
79
