System Overview

ArcSystem Pro One-Cell luminaires require an external driver.
Models are available to meet your installation requirements. This guide covers the products listed
below.
ArcSystem Pro One-Cell
external D1 Series or D4 Series driver required
•
ideal for short/medium throw
•
25 W full load power consumption
•
fixed version recessed/flush mount only
•
adjustable version recessed/flush mount with
•
two-axis tip and tilt
yoke-mount version with single-axis tilt
•
beam angle options: 18°, 30°, 50°
•
ArcSystem Pro One-Cell High Output
external D1 HO driver required
•
ideal for long throw
•
100 W full load power consumption
•
fixed version recessed/flush mount only
•
adjustable version recessed/flush mount with
•
two-axis tip and tilt
yoke-mount version with single-axis tilt
•
beam angle options: 18°, 30°, 50°
•
Note:
variants. The ArcSystem Pro One-Cell High Output is not available in 3500 K, 4000 K,
5000 K, or Fade to Warm variants.
ArcSystem Pro multi-cell luminaires are covered in the ArcSystem Pro Multi-Cell RDM Installation
Guide and ArcSystem Pro Installation Manual . All ETC manuals are available for download free of
charge at etcconnect.com.
D1 & D2 Series Drivers
The ArcSystem Pro One-Cell Micro is not available in 5000 K or Fade to Warm
ArcSystem Pro One-Cell Small
external D1 Series or D4 Series driver required
•
ideal for short/medium throw
•
25 W full load power consumption
•
adjustable version recessed/flush mount with
•
single-axis tilt
yoke-mount version with single-axis tilt
•
beam angle options: 19°, 24°, 37°, 60°
•
ArcSystem Pro One-Cell Micro
external D2 driver required
•
ideal for short/medium throw
•
20 W full load power consumption
•
adjustable version recessed/flush mount with
•
two-axis tip and tilt
yoke-mount version with single-axis tilt
•
beam angle options: 19°, 24°, 37°, 60°
•
