ArcSystem Pro Multi-Cell

System Overview

ArcSystem fixtures are available in 100–240 V or 100–277 V, standard or emergency models.
ArcSystem Pro One-Cell fixtures require an external driver.
Models are available to meet your installation requirements. This guide covers the products listed
below.
ArcSystem Pro Two-Cell
integral driver
•
ideal for medium throw
•
55 W full load power consumption
•
Standard: 100–240 V with IEC connector or 100–277 V
•
hard-wired input options
Emergency: 100–125 V with NEMA 5-15 connectors or
•
100–277 V hard-wired input options
yoke-mount only
•
beam angle options: 19°, 24°, 37°, 60°
•
ArcSystem Pro Eight-Cell
integral driver
•
ideal for long throw
•
200 W full load power consumption
•
Standard: 100–240 V with IEC connector or 100–277 V
•
hard-wired input options
Emergency: 100–125 V with NEMA 5-15 connectors or
•
100–277 V hard-wired input options
yoke-mount only
•
beam angle options: 19°, 24°, 37°, 60°
•
Note:
input. The ArcSystem Pro Four-Cell Round is only available with 100-240 V input with
IEC connectors (standard) or 100–125 V input with NEMA 5-15 connectors (emergency).
ArcSystem Pro One-Cell fixtures are covered in the ArcSystem Pro One-Cell Installation Guide and
ArcSystem Installation Manual . All ETC manuals are available for download free of charge at
etcconnect.com.
ArcSystem Pro Multi-Cell
The ArcSystem Pro One-Cell Pendant is only available with 100–277 V hard-wired
ArcSystem Pro Four-Cell
integral driver
•
ideal for medium/long throw
•
100 W full load power consumption
•
Standard: 100–240 V with IEC connector or 100–277 V
•
hard-wired input options
Emergency: 100–125 V with NEMA 5-15 connectors or
•
100–277 V hard-wired input options
linear and square yoke-mount, round, and pendant
•
options
beam angle options: 19°, 24°, 37°, 60°
•
