Example programs are included in the EZ-Board installation directory to
demonstrate UART and RS-232 operations.
For more information about the UART interface, refer to the
ADSP-214xx SHARC Processor Hardware Reference.

LEDs and Push Buttons

The EZ-Board has eight general-purpose user LEDs connected directly to
the processor, one EZ-Board power LED, and one board reset LED. The
EZ-board also has five push buttons: four general-purpose push buttons
connected directly to the processor and one push button for a board reset.
Table 1-3 summarizes LED connections to the processor. To use the
LEDs connected to DAI or DPI, configure the respective registers of the
processor. For more information, refer to the ADSP-214xx SHARC Proces-
sor Hardware Reference.
Table 1-3. LED Connections
LED Reference Designator
LED1
LED2
LED3
LED4
LED5
LED6
LED7
LED8
Two general-purpose push buttons are attached to the flag pins of the pro-
cessor, while the other two are attached to the DAI pins. All of the push
buttons and LEDs are connected to the processor through DIP switches.
ADSP-21479 EZ-Board Evaluation System Manual
Using The ADSP-21479 EZ-Board
Processor Pin
DPI_P6
DPI_P13
DPI_P14
DAI_P3
DAI_P4
DAI_P15
DAI_P16
DAI_P17
Connected via Switch
SW3.6
SW14.5
SW14.6
SW1.3
SW1.4
SW2.7
SW2.8
SW7.1
1-23
