Analog Devices ADSP-21479 EZ-Board Manual page 103

A
R374 R373
2.43K 2.67K
0402 0402
DAC3P
1
R375 R377
2.43K 2.67K
2
0402 0402
DAC3N
R346 R368
2.43K 2.67K
0402 0402
DAC4P
3
R347 R367
2.43K 2.67K
0402 0402
DAC4N
4
A
B
C206
680PF
0402
U28
5
7
6
AD8652ARZ
R372
SOIC_N8
750.0
0402
R370
6.81K
0603
C204 R371
620PF 4.99K
0402 0603
AD1939_VREF
R352
C205 4.99K
22UF 0603
ELEC_5MM
C194 R349
620PF 4.99K
0402 0603
R355
6.81K
R345 0603
750.0
0402
U28
2
1
3
AD8652ARZ
SOIC_N8
C207
680PF
0402
C203
680PF
0402
U30
5
7
6
AD8652ARZ
R376
SOIC_N8
750.0
0402
R356
6.81K
0603
C195 R350
620PF 4.99K
0402 0603
AD1939_VREF
R353
C196 4.99K
22UF 0603
ELEC_5MM
C201 R366
620PF 4.99K
0402 0603
R365
6.81K
R348 0603
750.0
0402
U30
2
1
3
AD8652ARZ
SOIC_N8
C202
680PF
0402
B
CT24
R361
22UF
100.0
ELEC_4MM
0402
OUT3P
R369
49.9K
0603
CT51
R351
U29 22UF
3 100.0
ELEC_4MM
0402
1 OUT2_SE_L
2
AD8652ARZ
R477
SOIC_N8
100K
0402
R357
4.99K
0603
CT23
R358
22UF
100.0
ELEC_4MM
0402
OUT3N
R363
49.9K
0603
CT27
R360
22UF
100.0
ELEC_4MM
0402
OUT4P
R364
49.9K
0603
CT52
R362
U29 22UF
5 100.0
ELEC_4MM
0402
7 OUT2_SE_R
6
AD8652ARZ
R478
SOIC_N8
100K
0402
R354
4.99K
0603
CT28
R359
22UF
100.0
ELEC_4MM
0402
OUT4N
R344
49.9K
0603
C
5V 5V 5V
C200 C199 C197
0.1UF 0.1UF 0.1UF
0402 0402 0402
MIddle Left (White)
J5
CON_RCA_6B
4
1
Middle Right (Red)
J5
CON_RCA_6B
6
2
ANALOG
DEVICES
ADSP-21479 EZ-BOARD
Title
Size Board No.
C
Date 3-15-2010_15:12
C
D
OUT2
1
AD1939_VREF
2
C268
0.1UF
0402
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
AUDIO PAGE 5
Rev
A0229-2009
0.1B
Sheet 13 of 17
