Analog Devices ADSP-21479 EZ-Board Manual page 96

A
3.3V
0402
R518
1 10K
U1
N10
SR_SCLK SR_SCLK SR_LD_O0
P10
SR_CLR SR_CLR SR_LD_O1
N12
SR_SDI SR_SDI SR_LD_O2
P11
SR_LAT SR_LAT SR_LD_O3
M10
SR_SDO_Z SR_SDO SR_LD_O4
SR_LD_O5
SR_LD_O6
SR_LD_O7
SR_LD_O8
SR_LD_O9
SR_LD_O10
SR_LD_O11
SR_LD_O12
SR_LD_O13
SR_LD_O14
SR_LD_O15
SR_LD_O16
SR_LD_O17
BGA196
2
3
SR_LD_O1
SR_LD_O3
SR_LD_O5
SR_LD_O7
SR_LD_O9
SR_LD_O11
SR_LD_O13
SR_LD_O15
SR_LD_O17
SR_CLR
SR_SCLK
4
A
B
NOTE: USED FOR INTERNAL TESTING ONLY
NOT POPULATED BY DEFAULT
M3
SR_LD_O0_Z
N2
SR_LD_O1_Z
P3
SR_LD_O2_Z
P2
SR_LD_O3_Z
N3
SR_LD_O4_Z
M6
SR_LD_O5_Z
P4
SR_LD_O6_Z
M7
SR_LD_O7_Z
N4
SR_LD_O8_Z
N7
SR_LD_O9_Z
N5
SR_LD_O10_Z
P8
SR_LD_O11_Z
P13 3.3V
SR_LD_O12_Z
N9
SR_LD_O13_Z
P12
SR_LD_O14_Z
P9
SR_LD_O15_Z
M9
SR_LD_O16_Z
N13
SR_LD_O17_Z
QS_EN
3.3V
"Serial SR header"
P4
1 2
3 4
SR_LD_O0
5 6
SR_LD_O2
7 8
SR_LD_O4
9 10
SR_LD_O6
11 12
SR_LD_O8
13 14
SR_LD_O10
15 16
SR_LD_O12
17 18
SR_LD_O14
19 20
SR_LD_O16
21 22
SR_SDI
23 24
SR_LAT
25 26
SR_SDO
13X2_2MM
B
3.3V
U5
2 46
SR_LD_O0 1A1 1B1
3 45
SR_LD_O1 1A2 1B2
4 44
SR_LD_O2 1A3 1B3
5 43
SR_LD_O3 1A4 1B4
6 42
SR_LD_O4 1A5 1B5
7 40
SR_LD_O5 1A6 1B6
9 39
SR_LD_O6 1A7 1B7
10 38
SR_LD_O7 1A8 1B8
11 37
SR_LD_O8 1A9 1B9
12 36
SR_LD_O9 1A10 1B10
48
1OE
13 35
SR_LD_O10 2A1 2B1
14 34
SR_LD_O11 2A2 2B2
16 33
SR_LD_O12 2A3 2B3
18 31
SR_LD_O13 2A4 2B4
19 30
SR_LD_O14 2A5 2B5
R516 20 29
SR_LD_O15 2A6 2B6
10K
0402 21 28
SR_LD_O16 2A7 2B7
DNP
22 27
SR_LD_O17 2A8 2B8
23 26
SR_LAT 2A9 2B9
24 25
2A10 2B10
47
2OE
SN74CB3Q16210
3.3V TSSOP48
DNP
R520
1.0K
0402
DNP
C295
0.1UF
0402
DNP
C
SR_LD_O2_Z
SR_LD_O4_Z
SR_LD_O3_Z
SR_LD_O1_Z
ADDR6
ADDR7
ADDR8
ADDR9
ADDR10
ADDR11
ADDR12 SR_LD_O10_Z
ADDR13
ADDR14 SR_LD_O6_Z
ADDR15 SR_LD_O8_Z
ADDR16
ADDR17
ADDR18
ADDR19
ADDR20
ADDR21 SR_LD_O0
ADDR22 SR_LD_O7
ADDR23 SR_LD_O5
ADDR2
SR_LD_O13_Z
SR_LD_O15_Z
DAI_P2_Z
SR_LD_O11_Z
SR_LD_O17_Z
SR_LD_O12_Z
SR_LD_O14_Z
SR_SDO_Z
ANALOG
DEVICES
ADSP-21479 EZ-BOARD
Title
DSP SHIFT REGISTER INTERFACE
Size Board No.
C
Date 3-9-2010_15:24
C
D
RN55
1 8
R1A R1B SR_LD_O2
2 7
R2A R2B SR_LD_O4
3 6
R3A R3B SR_LD_O3
4 5
R4A R4B SR_LD_O1
22 1
RNS005
RN56
1 8
R1A R1B SR_LD_O10
2 7
R2A R2B
3 6
R3A R3B SR_LD_O6
4 5
R4A R4B SR_LD_O8
22
RNS005
RN57
1 8
R1A R1B SR_LD_O0_Z
2 7
R2A R2B SR_LD_O7_Z
3 6
R3A R3B SR_LD_O5_Z
2
4 5
R4A R4B
22
RNS005
RN58
1 8
R1A R1B SR_LD_O13
2 7
R2A R2B SR_LD_O15
3 6
R3A R3B DAI_P2
4 5
R4A R4B SR_LD_O11
22
RNS005
RN59
1 8
R1A R1B
2 7
R2A R2B SR_LD_O17
3
3 6
R3A R3B SR_LD_O12
4 5
R4A R4B SR_LD_O14
22
RNS005
R521
22
0402
SR_SDO
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Rev
A0229-2009
0.1B
Sheet 6 of 17
D
