Ref.
Qty.
Description
45
1
IDC 30x2
IDC30X2_SMTA
46
1
2MM 13X2
13X2_2MM
47
8
YELLOW LED001
48
2
22PF 50V 5% 0805
49
2
0.22UF 25V 10%
0805
50
1
0.1UF 50V 10%
0805
51
1
600 100MHZ
200MA 0603
52
2
600 100MHZ
500MA 1206
53
2
10UF 16V 20%
CAP002
54
1
190 100MHZ 5A
FER002
55
8
10UF 6.3V 10%
0805
56
2
4.7UF 6.3V 10%
0805
57
32
0.1UF 10V 10%
0402
A-4
Reference
Designator
P2
P4
LED1-8
C262-263
C126-127
C123
FER1
FER2-3
CT59-60
FER4
C97-98,C100-
101,C254,C257,
C287-288
C240,C246
C53,C117-120,
C148,C151-152,
C160,C162,
C169-170,C178,
C188-189,C191,
C197,C199-200,
C211,C213-214,
C225,C227-228,
C264,C267-271,
C273
ADSP-21479 EZ-Board Evaluation System Manual
Manufacturer
Part Number
SAMTEC
TSSH-130-01-L-DV-A
SAMTEC
ETMM-113-02-L-D-SM
DIGI-KEY
P512TR-ND
AVX
08055A220JAT
AVX
08053C224KAT2A
AVX
08055C104KAT
DIGI-KEY
490-1014-2-ND
STEWARD
HZ1206B601R-10
PANASONIC
EEE1CA100SR
MURATA
DLW5BSN191SQ2
AVX
08056D106KAT2A
AVX
08056D475KAT2A
AVX
0402ZD104KAT2A
