MP JTAG Out Connector (P10)
Part Description
ERM8 10 x 2, RA male
6" cable ERF8 to ERM8 10 x 2
Standalone Debug Agent Connector (ZP1)
connects the standalone debug agent to the EZ-Board. The standalone
ZP1
debug agent requires two connectors,
see "JTAG Connector (P1)" on page 2-26.
ADSP-21479 EZ-Board Evaluation System Manual
ADSP-21479 EZ-Board Hardware Reference
Manufacturer
SAMTEC
Mating Cable
SAMTEC
ZP1
Part Number
ERM8-010-01-S-D-RA
ERCD-010-06.00-TBL-SBR-1
and
.
For more information,
P1
2-29
