LEDs and Push Buttons

This section describes the functionality of the LEDs and push buttons.
Figure 2-3
shows the locations of the LEDs and push buttons.
Figure 2-3. LED and Push Button Locations

Reset LED (LED1)

When
is lit, the master reset of all the major ICs is active.
LED1
ADSP-21161N EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
ADSP-21161N EZ-KIT Lite Hardware Reference
2-13
