2. Use the system configuration utility to connect to the EZ-Board.
If a debug configuration exists already, select the appropriate
configuration and click Apply and Debug or Debug. Go to step 8.
To create a debug configuration, do one of the following:
• Click the down arrow next to the little bug icon, select
Debug Configurations
• Choose Run > Debug Configurations.
The Debug Configuration dialog box appears.
3. Select CrossCore Embedded Studio Application and click
(New launch configuration).
The Select Processor page of the Session Wizard appears.
4. Ensure Blackfin is selected in Processor family. In Processor type,
select ADSP-21479. Click Next.
The Select Connection Type page of the Session Wizard appears.
5. Select one of the following:
• For standalone debug agent connections, EZ-Board and
click Next.
• For emulator connections, Emulator and click Next.
The Select Platform page of the Session Wizard appears.
