DAI [1–8] Enable Switch (SW1)
The DAI [1–8] enable switch (
eight on the processor from the associated peripherals on the EZ-Board
and allows the DAI signals to be used on the expansion II interface. See
Table 2-4.
Table 2-4. DAI [1–8] Enable Switch (SW1)
SW1 Position
SW1.1
SW1.2
SW1.3
SW1.4
SW1.5
SW1.6
SW1.7
SW1.8
DAI [9–16] Enable Switch (SW2)
The DAI [9–16] enable switch (
through 16 on the processor from the associated peripherals on the
EZ-Board and allows the DAI signals to be used on the expansion II inter-
face. See Table
Table 2-5. DAI [9–16] Enable Switch (SW2)
SW2 Position
SW2.1
SW2.2
2-8
SW1
DAI Pin Peripheral
S/PDIF
DAI_P1
AD1939
DAI_P2
LEDs
DAI_P3
LEDs
DAI_P4
AD1939
DAI_P5
AD1939
DAI_P6
AD1939
DAI_P7
AD1939
DAI_P8
SW2
2-5.
DAI Pin Peripheral
AD1939
DAI_P9
AD1939
DAI_P10
ADSP-21479 EZ-Board Evaluation System Manual
) disconnects DAI pins one through
Peripheral Net
SPDIF_OUT
AD1939_SOFT_RESET
LED4
LED5
ASDATA1
ASDATA2
ABCLK
ALRCLK
) disconnects DAI pins nine
Peripheral Net
DSDATA4
DSDATA3
Switch Setting
(Default)
ON
ON
ON
ON
ON
ON
ON
ON
Switch Setting
(Default)
ON
ON
