Expansion Interface II Connector (J1)
is a board-to-board connector providing signals from the asynchronous
J1
memory interface (AMI) of the processor. The connector is located on the
right edge of the board. For more information, see
II" on page
1-26. For availability and pricing of the connector, contact
Samtec.
Part Description
104-position 0.025", SMT header
104-position 0.025", SMT socket
RS-232 Connector (J2)
Part Description
DB9, female, vertical mount
2m female-to-female cable
MP JTAG Connector (J3)
Part Description
ERF8 10 x 2, RA female
6" cable ERF8 to ERM8 10 x 2
2-24
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
NORCOMP
Mating Cable
DIGI-KEY
Manufacturer
SAMTEC
Mating Cable
SAMTEC
ADSP-21479 EZ-Board Evaluation System Manual
"Expansion Interface
Part Number
QMS-052-06.75-L-D-A
QFS-052-04.25-L-D-A
Part Number
191-009-213-L-571
AE1020-ND
Part Number
ERF8-010-01-S-D-RA-L
ERCD-010-06.00-TBL-SBR-1
