LEDs and Push Buttons
This section describes the functionality of the LEDs and push buttons.
Figure 2-3
shows the locations of the LEDs and push buttons.
Figure 2-3. LED and Push Button Locations
ADSP-21161N EZ-KIT Lite Evaluation System Manual
USB Monitor: LED10
VERF:
LED9
DSP Reset:
LED8
Reset:
LED1
Power: LED11
FLAG4-9: LED2 - 7
Reset:
SW8
IRQ0-2:
SW5-7
FLAG0-3:
SW1-4
EZ-KIT Lite Hardware Reference
2-13
