A ADSP-21479 EZ-BOARD BILL
OF MATERIALS
The bill of materials corresponds to
on page B-1.
Ref. Qty. Description
1 1 74LVC14A SOIC14
2 1 IDT74FCT3244AP
Y SSOP20
3 1 12.288MHZ
OSC003
4 1 32.768KHZ
OSC008
5 4 SN74LVC1G08
SOT23-5
6 1 24.576MHZ
OSC003
7 1 SN65LVDS2D
SOIC8
8 1 M25P16 SO8W
9 2 SI7601DN ICS010
10 1 MT48LC16M16A2
TSOP54
11 1 IS61WV102416BL
L TSOP48
12 1 2MHz OSC015
ADSP-21479 EZ-Board Evaluation System Manual

"ADSP-21479 EZ-Board Schematic"

Reference Manufacturer
Designator
U14 TI
U17 IDT
U12 EPSON
U7 EPSON
U9,U13,U27,U41 TI
U39 EPSON
U11 NATIONAL
SEMI
U6 NUMONYX
U15-16 VISHAY
U2 MICRON
U3 ISSI
U40 MURATA
Part Number
74LVC14AD
IDT74FCT3244APYG
SG-8002CA MP
MC-156-32.7680KA-
A0:ROHS
SN74LVC1G08DBVR
SG-8002CA MP
DS90LV018ATM
M25P16-VMW6G
SI7601DN
MT48LC16M16A2P-
6A:D
IS61WV102416BLL-
10TLI
CSTCC2M00G56-
R0(2MHz)
A-1
