Ref. Qty. Description
13 1 16.625MHZ
OSC003
14 1 21479
M29W320EB "U4"
15 1 ADM708SARZ
SOIC8
16 1 ADM3202ARNZ
SOIC16
17 1 ADSP-21479
BGA196
18 2 ADP1864AUJZ
SOT23-6
19 1 ADP1710 TSOT5
20 1 AD1939 LQFP64
21 16 AD8652ARZ
SOIC_N8
22 1 AD8397
SOIC_N8_EP
23 1 ADM1085 SC70_6
24 2 RCA 1X1 CON012
25 5 MOMENTARY
SWT013
26 4 DIP8 SWT016
27 6 DIP6 SWT017
28 3 DIP4 SWT018
A-2
Reference
Designator
U42
U4
U18
U8
U1
VR2-3
VR1
U19
U20-26,U28-30,
U32-34,U36-38
U31
U35
J6-7
SW8-12
SW1-3,SW19
SW13-18
SW7,SW24-25
ADSP-21479 EZ-Board Evaluation System Manual
Manufacturer Part Number
EPSON SG-8002CA-MPT
NUMONYX M29W320EB70ZE6E
ANALOG ADM708SARZ
DEVICES
ANALOG ADM3202ARNZ
DEVICES
ANALOG ADSP-21479KBCZ-
DEVICES ENG
ANALOG ADP1864AUJZ-R7
DEVICES
ANALOG ADP1710AUJZ-R7
DEVICES
ANALOG AD1939YSTZ
DEVICES
ANALOG AD8652ARZ
DEVICES
ANALOG AD8397ARDZ-REEL7
DEVICES
ANALOG ADM1085AKSZ-REEL7
DEVICES
SWITCH- PJRAN1X1U01X
CRAFT
PANASONIC EVQ-PAD04M
C&K TDA08H0SB1
CTS 218-6LPST
ITT TDA04HOSB1
