The input clock is 16.625 MHz. The default boot mode of the processor
is external parallel flash boot. See
page 2-10 for information on how to change the default boot mode.

DAI Interface

The digital application interface (DAI) pins are connected to the signal
routing unit (SRU) of the processor. The SRU is a flexible routing system
providing a large system of signal flows within the processor. The SRU
allows you to route the DAI pins to different internal peripherals in vari-
ous combinations.
The DAI connects various peripherals on the EZ-Board.
the DAI pin names, associated peripheral and net names, switch designa-
tors through which the pins are connected to the peripherals, and default
switch settings.
Table 2-1. DAI Connections
DAI Pin
DAI_P1
DAI_P2
DAI_P3
DAI_P4
DAI_P5
DAI_P6
DAI_P7
DAI_P8
DAI_P9
DAI_P10
DAI_P11
DAI_P12
ADSP-21479 EZ-Board Evaluation System Manual
ADSP-21479 EZ-Board Hardware Reference
Peripheral Peripheral Net
S/PDIF
SPDIF_OUT
AD1939
SOFT_RESET
LEDs
LED4
LEDs
LED5
AD1939
ASDATA1
AD1939
ASDATA2
AD1939
ABCLK
AD1939
ALRCLK
AD1939
DSDATA4
AD1939
DSDATA3
AD1939
DSDATA2
AD1939
DSDATA1
"Boot Mode Select Switch (SW4)" on
Connected via
Switch
SW1.1
SW1.2
SW1.3
SW1.4
SW1.5
SW1.6
SW1.7
SW1.8
SW2.1
SW2.2
SW2.3
SW2.4
Table 2-1 shows
Switch Setting
(Default)
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
