- Page 1 ® EV-21593-SOM Manual Revision 1.0, September 2020 Part Number 82-EV-21593-SOM-01 Analog Devices, Inc. One Technology Way Norwood, MA 02062-9106...
- Page 2 Analog Devices, Inc. reserves the right to change this product without prior notice. Information furnished by Ana- log Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use; nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent rights of Analog Devices, Inc.
-
Page 3: Table Of Contents
Manual Contents ............................1–1 Technical Support ............................1–2 Supported Integrated Circuit ......................... 1–2 Supported Tools............................. 1–3 Product Information ............................1–3 Analog Devices Website..........................1–3 EngineerZone ............................. 1–3 Using the Board Product Overview ............................2–1 Package Contents............................2–3 Default Configuration ........................... 2–3 CrossCore Embedded Studio (CCES) Setup .................... - Page 4 Reset ( LED6 )............................3–12 Connectors ..............................3–12 JTAG ( P1 ).............................. 3–13 MicroUSB Connector ( P2 ) ........................3–13 USB Type C Connector ( P3 )........................3–14 SoM Interface Connection ( J1,J2 and J3 )..................3–14 ® EV-21593-SOM Manual...
-
Page 5: Preface
(CCES) software development tool chain is required for a full evaluation of this hardware platform. The EV-21593-SOM can also be used in a limited standalone mode while not plugged into a SoM Carrier such as the EV-SOMCRR-EZKIT or EV-SOMCRR-AUTO . The standalone mode is useful for evaluat- ing the CCES Software Development Tools and benchmarking software algorithms that do not require peripheral I/O. -
Page 6: Technical Support
A companion file in PDF format documenting all of the circuits used on the board is available on the website http://www.analog.com/EV-21593-SOM Technical Support You can reach Analog Devices technical support in one of the following ways: • Post your questions in the processors and DSP support community at EngineerZone ®... -
Page 7: Supported Tools
If you are a registered user, just log on. Your user name is your e-mail address. EngineerZone EngineerZone is a technical support forum from Analog Devices, Inc. It allows you direct access to ADI technical support engineers. You can search FAQs and technical information to get quick answers to your embedded process- ing and DSP design questions. -
Page 8: Using The Board
This chapter provides information on the major components and peripherals on the board, along with instructions for installing and setting up the emulation software. Product Overview Below is an image of the EV-21593-SOM board. Figure 2-1: Board View ® 2–1... - Page 9 Product Overview The board features: • Analog Devices ADSP-21593 processor • Dual SHARC+ Cores • 400 ball BGA • 25 MHz oscillator • DDR3 Memory • 512Mx16 bit (8Gbit ) • ISSI IS43TR16512BL-125KBL • 1.35V • SPI Flash Quad (SPI2) Memory •...
-
Page 10: Package Contents
Package Contents Your EV-21593-SOM package contains the following items. • EV-21593-SOM board Contact the vendor where you purchased your EV-21593-SOM evaluation board or contact Analog Devices, Inc. if any item is missing. Default Configuration The EV-21593-SOM board is designed to run as a standalone unit. -
Page 11: Crosscore Embedded Studio (Cces) Setup
ICE-2000 to for debugging. When the EV-21593-SOM is connected to a carrier board the Debug Agent on the carrier board can be used. To use this Debug Agent, all postions on SW1 (on the carrier board) must be in the ON position. If an emulator, such as the ICE-1000 or ICE-2000, is used instead all postions on SW1 must be in the OFF position. -
Page 12: Power-On-Self Test
The EV-21593-SOM powered via when the board is in standalone mode. When in this mode the jumper on JP1 should be on Pins 1-2 to select power input from . When the EV-21593-SOM is connected to a carrier board the power is supplied via the carrier board. -
Page 13: Is43Tr16512Bl - 1Gx8, 512Mx16 8Gb Ddr3 Sdram
• Asynchronous RESET pin • TDQS (Termination Data Strobe) supported (x8 only) • OCD (Off-Chip Driver Impedance Adjustment) • Dynamic ODT (On-Die Termination) • Driver strength : RZQ/7, RZQ/6 (RZQ = 240 Ω) • Write Leveling 2–6 ® EV-21593-SOM Manual... -
Page 14: Lt8636 - 42V, 5A/7A Peak Synchronous Step-Down Silent Switcher With 2.5Μa Quiescent Current
5MHz. For systems with higher power requirements, multi-phasing parallel converters is readily implemented. The LTC3310S uses a constant-frequency, peak current mode control architecture for fast transient response. A 500mV reference allows for low voltage outputs. 100% duty cycle operation delivers low drop out. ® 2–7 EV-21593-SOM Manual... -
Page 15: Adp151 - Ultralow Noise, 200 Ma, Cmos Linear Regulator
Thanks to its 20 V technology, it implements high voltage fea- tures to protect the CC pins against short-circuits to VBUS up to 22 V and to support high voltage on the VBUS pins directly connected to the VBUS power path up to 28 V. 2–8 ® EV-21593-SOM Manual... -
Page 16: Hardware Reference
Hardware Reference 3 Hardware Reference This chapter describes the hardware design of the EV-21593-SOM . System Architecture The board's configuration is shown in the Block Diagram figure. ® 3–1 EV-21593-SOM Manual... -
Page 17: Software-Controlled Switches (Softconfig)
C software-control- led switches. The remaining mechanical switches are provided for the boot mode and pushbuttons. Reference any SoftConfig*.c file found in the installation directory for an example of how to set up the SoftConfig feature of 3–2 ® EV-21593-SOM Manual... -
Page 18: Overview Of Softconfig
EXAMPLE_SIGNAL_B, the Microchip IO expander is used to change ENABLE_A to a logic 1 through software that interfaces with the Microchip. The same procedure for ENABLE_B disconnects EXAMPLE_SIGNAL_C from EXAMPLE_SIGNAL_D. Figure 3-2: Example of Individual FET Switches ® 3–3 EV-21593-SOM Manual... - Page 19 In this example, the Microchip IO expander is not shown but controls the signal CONTROL_LETTER_NUMBER and allows the user to change the selection through software. 3–4 ® EV-21593-SOM Manual...
- Page 20 SWE and SWF is OFF. In order to connect the letters instead of the numbers, the user physically changes all switches on SWC and SWD to the OFF position and all switches on SWE and SEF to the ON position. ® 3–5 EV-21593-SOM Manual...
-
Page 21: Softconfig On The Board
Enabled Programming SoftConfig Switches On the board, two Microchip MCP23017 devices exist. Each of these devices have the following programming characteristics: • Each GPIO register controls eight signals (software switches). GPIO Register Register Address GPIOA 0x12 3–6 ® EV-21593-SOM Manual... - Page 22 FET column. The Component Connected column shows the board IC that is connected if the FET is enabled. The Microchip (U47) is controlling the enable signal of a FET switch. Also note that if a particular functionality of the processor signal is being used, it is in bold font in the Processor Signal column. ® 3–7 EV-21593-SOM Manual...
- Page 23 Table 3-5: Output Signals of Microchip GPIO Expander (U13 Port B) Signal Name Description Processor Signal Connected Default (if applicable) NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED 3–8 ® EV-21593-SOM Manual...
-
Page 24: Switches
By default, the processor boots from SPI2 master boot which uses the on-board SPI flash memory. Table 3-6: Boot Mode Switch Position Processor Boot Mode No Boot SPI Master Boot (Default) ® 3–9 EV-21593-SOM Manual... -
Page 25: Reset Pushbutton ( Sw2 )
Pin 2-3 selects Power from the SoM Interface Connection. When using the EV-SOMCRR-EZ- KIT or other plug in base board, use Jumper setting Pin 2-3. LEDs This section describes the on-board LEDs. The LED Locations figure shows the LED locations. 3–10 ® EV-21593-SOM Manual... -
Page 26: Fault ( Led1 )
Three LEDs are connected to the SoftConfig(see the GPIO LEDs table). The LEDs are active high and are turned ON (amber) by writing to the U13 SoftConfig IC. Table 3-7: GPIO LEDs Reference Designator Programmable Flag Pin LED2 SoftSwitch LED4 SoftSwitch ® 3–11 EV-21593-SOM Manual... -
Page 27: Reset ( Led6 )
LED. For more information, see Reset Pushbutton ( SW2 Connectors This section describes connector functionality and provides information about mating connectors. The connector locations are shown in the Connector Locations figure. JTAG Micro Power Figure 3-8: Connector Locations Top View 3–12 ® EV-21593-SOM Manual... -
Page 28: Jtag ( P1 )
Devices emulators. For more information, see Debug Interface MicroUSB Connector ( P2 ) USB Connection for FTDI RS232 to USB connection. Part Description Manufacturer Part Number MicroUSB 2.0 Hirose ZX62D-AB-5P8(30) Mating Cable USB A to MicroUSB ® 3–13 EV-21593-SOM Manual... -
Page 29: Usb Type C Connector ( P3 )
These signals are based upon the peripheral signal needs, which allows multiple DSPs to be used with this connec- tion. These connectors are self-mating and the pinout here reflects the connectors on the EV-21593-SOM. Table 3-8: SoM Interface A Connector... - Page 30 SPI1_MISO UART1_RTSb LINKPORT1_D0 OSPI_D5 TWI1_SDA LINKPORT0_ACK SPI1_MOSI UART1_CTSb LINKPORT1_ACK OSPI_D6 TWI2_SCL GND9 LINKPORT0_CLK SPI1_SSb UART2_TXb GND10 LINKPORT1_CLK Table 3-10: SoM Interface C Connector Signal Signal Signal Signal Signal GND1 GND7 GND2 GND4 CLK1 GPIO3 CLK2 GPIO4 ® 3–15 EV-21593-SOM Manual...
- Page 31 JTG0_TRST GND10 SoM_Reset VDD1 SYS_CLKOUT TARGET_RESET 78 GPIO1 VSS1 GND6 VDD2 AUDIO_CLK GND9 GPIO2 VSS2 Table 3-11: Mating Connector Part Description Manufacturer Part Number 100-pin, 0.64 mm SAMTEC LSS-150-01-L-DV-A-K Mating Connector 100-pin, 0.64 mm SAMTEC LSS-150-01-L-DV-A-K 3–16 ® EV-21593-SOM Manual...
- Page 32 ® EV-21593-SOM Manual...
