ADSP-21161N EZ-KIT Lite
®
Evaluation System Manual
Revision 4.0, October 2006
Part Number
82-000530-01
Analog Devices, Inc.
One Technology Way
a
Norwood, Mass. 02062-9106
www.BDTIC.com/ADI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSP-21161N EZ-KIT Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Analog Devices ADSP-21161N EZ-KIT Lite

Summary of Contents for Analog Devices ADSP-21161N EZ-KIT Lite

  • Page 1 ADSP-21161N EZ-KIT Lite ® Evaluation System Manual Revision 4.0, October 2006 Part Number 82-000530-01 Analog Devices, Inc. One Technology Way Norwood, Mass. 02062-9106 www.BDTIC.com/ADI...
  • Page 2 Analog Devices or from an authorized dealer. Disclaimer Analog Devices, Inc. reserves the right to change this product without prior notice. Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use;...
  • Page 3 Regulatory Compliance The ADSP-21161N EZ-KIT Lite evaluation system has been certified to comply with the essential requirements of the European EMC directive 89/336/EEC (inclusive 93/68/EEC) and, therefore, carries the “CE” mark. The ADSP-21161N EZ-KIT Lite evaluation system had been appended to Analog Devices Development Tools Technical Construction File refer- enced “DSPTOOLS1”...
  • Page 4 www.BDTIC.com/ADI...

  • Page 5: Table Of Contents

    Accessing Documentation From VisualDSP++ ....... xx Accessing Documentation From Windows ......xx Accessing Documentation From Web ........xxi Printed Manuals ............... xxi VisualDSP++ Documentation Set ......... xxi Hardware Tools Manuals ............. xxii Processor Manuals ............... xxii ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 6 Host Processor Interface (HPI) ..........2-4 SPORT Audio Interface ............2-4 SPI Audio Interface ..............2-4 JTAG Emulation Port ............. 2-5 Switch and Jumper Settings ............2-5 Clock Mode Selection Switch (SW10) ........2-5 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 7 VERF LED (LED12) ............2-14 Power LED (LED11) ............. 2-14 USB Monitor LED (ZLED3) ..........2-15 Programmable Flag Push Buttons (SW1–4) ......2-15 Interrupt Push Buttons (SW5–7) ........... 2-15 Board Reset Push Button (SW12) .......... 2-16 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 8 SPI Connector (P18) ............. 2-21 JTAG Connector (ZP4) ............2-21 Specifications ................2-22 Power Supply ................ 2-22 Board Current Measurements ..........2-22 ADSP-21161N EZ-KIT LITE BILL OF MATERIALS ADSP-21161N EZ-KIT LITE SCHEMATIC Title Page ..................B-1 ADSP-21161N Processor .............. B-2 Memory ..................B-3 S/PDIF Receiver ................
  • Page 9 Audio Out 1 ................B-9 Audio Out 2 ................B-10 Audio Out 3 ................B-11 Audio Out 4 ................B-12 Push Buttons ................B-13 LEDs, RESET, and Oscillators ........... B-14 Connectors ................B-15 Power ..................B-16 INDEX ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 10 CONTENTS ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 11 PREFACE ® Thank you for purchasing the ADSP-21161N EZ-KIT Lite , Analog ® Devices, Inc. evaluation system for SHARC digital signal processors (DSPs). SHARC processors are based on a 32-bit super Harvard architecture that includes a unique memory architecture comprised of two large on-chip,...
  • Page 12 The ADSP-21161N EZ-KIT Lite provides example programs to demon- strate the capabilities of the evaluation board. The ADSP-21161N EZ-KIT Lite installation is part of the Visu- alDSP++ installation. The EZ-KIT Lite is a licensed product that offers an unrestricted evaluation license for the first 90 days. For details about evaluation license restrictions after the 90 days, refer “Evaluation License Restrictions”...
  • Page 13 The EZ-KIT Lite board has a flash memory device that can be used to store user-specific boot code. By configuring the switch for EPROM boot, the board can run as a stand-alone unit. The ADSP-21161N EZ-KIT Lite package contains a flash programmer utility, which allows you to program the flash memory.

  • Page 14: Purpose Of This Manual

    VisualDSP++ Installation Quick Reference Card. The manual provides guidelines for running your own code on the ADSP-21161N EZ-KIT Lite. Finally, a schematic and a bill of materials are provided as a reference for future designs.

  • Page 15: Manual Contents

    ADSP-21161N EZ-KIT Lite Evaluation System Manual is located in the folder on the installation Docs\EZ-KIT Lite Manuals CD. Alternatively, the book can be found on the Analog Devices Web site, www.analog.com/processors What’s New in This Manual This edition of the ADSP-21161N EZ-KIT Lite Evaluation System Manual documents the ADSP-21161N EZ-KIT Lite compliance with the RoHS and WEEE directives.

  • Page 16: Technical Or Customer Support

    Technical or Customer Support Technical or Customer Support You can reach Analog Devices, Inc. Customer Support in the following ways: • Visit the Embedded Processing and DSP products Web site at http://www.analog.com/processors/technicalSupport • E-mail tools questions to processor.tools.support@analog.com • E-mail processor questions to processor.support@analog.com (World wide support)

  • Page 17: Product Information

    MyAnalog.com MyAnalog.com is a free feature of the Analog Devices Web site that allows customization of a Web page to display only the latest information on products you are interested in. You can also choose to receive weekly e-mail notifications containing updates to the Web pages that meet your interests.

  • Page 18: Related Documents

    Product Information You may also obtain additional information about Analog Devices and its products in any of the following ways. • E-mail questions or requests for information to processor.support@analog.com (World wide support) processor.europe@analog.com (Europe support) processor.china@analog.com (China support) • Fax questions or requests for information to...

  • Page 19: Online Technical Documentation

    You can easily search across the entire VisualDSP++ documentation set for any topic of interest. For easy printing, supplementary files of most manuals are provided in the .pdf folder on the VisualDSP++ installation CD. Docs ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 20: Accessing Documentation From Visualdsp

    To view VisualDSP++ Help, click on the Help menu item or go to the Windows task bar and navigate to the VisualDSP++ documentation via the Start menu. To view ADSP-21161N EZ-KIT Lite Help, which is part of the Visu- alDSP++ Help system, use the Contents or Search tab of the Help window.

  • Page 21: Accessing Documentation From Web

    To purchase VisualDSP++ manuals, call 1-603-883-2430. The manuals may be purchased only as a kit. If you do not have an account with Analog Devices, you are referred to Analog Devices distributors. For information on our distributors, log onto http://www.analog.com/salesdir/continent.asp ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 22: Hardware Tools Manuals

    1-800-ANALOGD (1-800-262-5643); they also can be downloaded from the Web site. To have a data sheet faxed to you, call the Analog Devices Faxback System at 1-800-446-6212. Follow the prompts and a list of data sheet code numbers will be faxed to you. If the data sheet you want is not listed, check for it on the Web site.
  • Page 23 A Warning identifies conditions or inappropriate usage of the product that could lead to conditions that are potentially hazardous for the devices users. In the online version of this book, the word Warning appears instead of this symbol. ADSP-21161N EZ-KIT Lite Evaluation System Manual xxiii www.BDTIC.com/ADI...
  • Page 24 Notation Conventions xxiv ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 25: Using Adsp-21161N Ez-Kit Lite

    1 USING ADSP-21161N EZ-KIT LITE This chapter provides specific information to assist you with development of programs for the ADSP-21161N EZ-KIT Lite evaluation system. The information appears in the following sections. • “Package Contents” on page 1-2 Lists the items contained in the ADSP-21161N EZ-KIT Lite package.

  • Page 26: Package Contents

    For detailed information on how to program the ADSP-21161N SHARC processor, refer to the documents referenced in “Related Documents”. Package Contents Your ADSP-21161N EZ-KIT Lite evaluation system package contains the following items. • ADSP-21161N EZ-KIT Lite board • VisualDSP++ Installation Quick Reference Card ADSP-21161N EZ-KIT Lite Evaluation System Manual...

  • Page 27: Default Configuration

    Store unused EZ-KIT Lite boards in the protective shipping package. The ADSP-21161N EZ-KIT Lite board is designed to run outside your personal computer as a stand-alone unit. You do not have to open your computer case.
  • Page 28 Figure 1-1 shows the default jumper settings, switches, connector locations, and LEDs used in installation. Confirm that your board is set up in the default configuration before continuing. Figure 1-1. EZ-KIT Lite Hardware Setup ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 29: Installation And Session Startup

    VisualDSP++ to start a new session by pressing and holding down the Ctrl key while starting VisualDSP++. Do not release the Ctrl key until the Session Wizard appears on the screen. Go to step 4. ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 30 VisualDSP++ creates a session name by combining the name of the selected platform with the selected processor. The only way to change a session name later is to delete the session and to open a new session. Click Next. ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 31: Evaluation License Restrictions

    Delete. Click OK. Evaluation License Restrictions The ADSP-21161N EZ-KIT Lite installation is part of the VisualDSP++ installation. The EZ-KIT Lite is a licensed product that offers an unre- stricted evaluation license for the first 90 days. Once the initial unrestricted 90-day evaluation license expires: •...

  • Page 32: Memory Map

    The configuration of internal SRAM is detailed in the ADSP-21161 SHARC Processor Hardware Reference. The ADSP-21161N EZ-KIT Lite board contains 512K x 8-bits of exter- nal flash memory. The flash memory connects to the processors’s ~MS1 memory select pins.

  • Page 33: Sdram Memory

    MODE2 read though the registers. The registers are summarized in FLAGS FLAGS Table 1-2. For more information on flags, refer to the ADSP-21161 SHARC Processor Hardware Reference. ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 34: Interrupt Pins

    SW5–7 EZ-KIT Lite board. Interrupt pins are summarized in Table 1-3. For more information, refer to the ADSP-21161 SHARC Processor Hardware Reference. 1-10 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 35: Audio Interface

    24-bit conversion resolution and a 96 kHz sample rate. The AD1836 features a 108 dB dynamic range for each of its six DACs and a 104 dB dynamic range for its four ADCs. The AD1836 is ADSP-21161N EZ-KIT Lite Evaluation System Manual 1-11 www.BDTIC.com/ADI...
  • Page 36 ) to indicate that the audio out- VERF put may not be valid. This signal connects to a LED ( ) on the board LED12 and also can be used by interpolation filters to provide error correction. 1-12 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 37: Example Programs

    Using ADSP-21161N EZ-KIT Lite Example Programs Example programs are provided with the ADSP-21161N EZ-KIT Lite to demonstrate various capabilities of the evaluation board. These programs are installed with the EZ-KIT Lite software and can be found in the subdirectory of the Visu- …\211xx\Examples\ADSP-21161 EZ-KIT Lite...
  • Page 38 Flash Programmer Utility 1-14 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 39: Adsp-21161N Ez-Kit Lite Hardware Reference

    This chapter describes the hardware design of the ADSP-21161N EZ-KIT Lite board. The following topics are covered. • “System Architecture” on page 2-2 Describes the configuration of the ADSP-21161N EZ-KIT Lite board and explains how the board components interface with the processor. •...

  • Page 40: System Architecture

    Reciever or COAX input Stereo Amplifiers Stereo Amplifiers A5V 3.3V 1.8V RCA Phono Line RCA Phono Line IN(2) OUT(6) OUT(2) Power Connectors 1/8" Connectors Regulatiors Mic Connector Figure 2-1. System Architecture Block Diagram ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 41: External Port

    ) as described in “Clock Mode Selection Switch (SW10)” on SW10 page 2-5 Table 2-1. By default, the processor core runs at 100 MHz. Table 2-1. ADSP-21161N EZ-KIT Lite Clock Modes CLKDBL CLK_CFG1 CLK_CFG0 Core Clock Ratio EP Clock Ratio...

  • Page 42: Host Processor Interface (Hpi)

    Some of the address, data, and control signals are available externally via two off-board connectors. The EP connector pinout ( ) can be found in “ADSP-21161N EZ-KIT Lite Schematic” on page B-1. Host Processor Interface (HPI) The host port interface (HPI) signals are brought to an unpopulated off-board connector ( ).

  • Page 43: Jtag Emulation Port

    14-pin header. For a detailed description of the interface connectors, see EE-68 published on the Analog Devices Web site (go to and search http://www.analog.com for EE-68). For more information about the JTAG connection, see “JTAG...
  • Page 44 Pins 5 & 6 Ratio Clock Ratio Not installed Installed Installed Not installed Installed Not installed Not installed Not installed Installed 1x (default) Installed Installed Installed Installed Installed Not installed Installed Not installed Installed ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 45: Boot Mode Selection Switch (Sw11)

    ~BMS grounded, and the flash memory is selected. For more information on boot modes, see “Boot Mode Selection Switch (SW11)” on page 2-7. ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 46: Sdram Disable Jumper (P17)

    ) for the MCLK AD1836 and AD1852 audio devices. Table 2-5. MCLK Selection (JP3) Jumper Location MCLK Source 1 and 2 Audio oscillator (12.288 MHz) (default) 2 and 3 Derived clock from S/PDIF stream ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 47: Flag0 Enable Jumper (Jp1 And Jp4)

    Jumper Location Sample Frequency None installed Not allowed 3 and 4 192 kHz (2x interpolator) 1 and 2 96 kHz (4x interpolator) 1 and 2, 3 and 4 48 kHz (8x interpolator) (default) ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 48: Adc2 Input Mode Selection Jumpers (Jp7 And Jp8)

    ADC2 used. If a microphone is used, the gain of the circuit can be increased as described in “MIC Gain Selection Jumpers (JP9 and JP10)” on page 2-10. 2-10 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 49: Ad1836 Control Selection Jumper (Jp23)

    SW1 Enable Jumper (JP26) push button is attached though a driver to of the processor. FLAG0 To disconnect the driver from (for example, to use as an out- FLAG0 FLAG0 put), remove JP26 ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-11 www.BDTIC.com/ADI...

  • Page 50: Sw2 Enable Jumper (Jp27)

    Resistors Installed Resistors Uninstalled Description R144, R145, R146 R155, R156, R157 Single processor (default) R144, R145, R157 R146, R155, R156 Processor 1 R144, R146, R156 R145, R155, R157 Processor 2 Other Invalid 2-12 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 51: Leds And Push Buttons

    LEDs and push buttons. Figure 2-3. LED and Push Button Locations Reset LED (LED1) When is lit, the master reset of all the major ICs is active. LED1 ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-13 www.BDTIC.com/ADI...

  • Page 52: Flag Leds (Led2-7)

    CS8416 digital receiver. The error can occur when digital audio cables disconnect from the optical or coaxial SPDIF connectors. Power LED (LED11) When is lit (green), it indicates that power is being properly sup- LED11 plied to the board. 2-14 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 53: Usb Monitor Led (Zled3)

    Three push buttons ( ) are provided for general-purpose user inter- SW5—7 rupts. The push buttons connect to the processor’s programmable flag pins. The push buttons are active high and, when pressed, send a high ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-15 www.BDTIC.com/ADI...

  • Page 54: Board Reset Push Button (Sw12)

    Pressing the push button ( ) while VisualDSP++ is run- RESET SW12 ning disrupts communication and causes errors in the current debug session. VisualDSP++ must be closed and re-opened. 2-16 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 55: Connectors

    This section describes the connector functionality and provides informa- tion about mating connectors. Figure 2-4 shows the connector locations. Figure 2-4. Connector Locations USB Connector (ZJ1) The USB connector ( ) is a standard Type B USB receptacle. ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-17 www.BDTIC.com/ADI...

  • Page 56: Audio Connectors (J2-6, P4)

    Digital fiber-optic cable ( MONSTER CABLE ILS100-1M External Port Connector (P9) A 40-pin 0.05’ spacing connector provides access to some of the proces- sor’s external port signals. By default, is not populated. 2-18 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 57: Host Processor Interface Connector (P10)

    SPORT1 and SPORT3 Connector (P12) connect to a 20-pin connector SPORT1 SPORT3 Part Description Manufacturer Part Number 20-position AMPMODU system TYCO 5-104069-1 50 receptacle Mating Connectors 20-position AMPMODU system 2-487937-0 20 connector ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-19 www.BDTIC.com/ADI...

  • Page 58: Link Port Connectors (P13 And P14)

    EZ-KIT Lite board. Part Description Manufacturer Part Number 2.5 mm power jack ( SWITCHCRAFT RAPC712X DIGI-KEY RAPC712X-ND Mating Power Supply (shipped with EZ-KIT Lite) 7V power supply CUI STACK DTS070175SUDC-P6-SZ 2-20 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 59: Spi Connector (P18)

    Pin 3 is missing to provide keying. Pin 3 in the mating connector should have a plug. When using an emulator with the EZ-KIT Lite board, follow the connection instructions provided with the emulator. Part Description Manufacturer Part Number 14-pin IDC header ( 68737-414HLF ADSP-21161N EZ-KIT Lite Evaluation System Manual 2-21 www.BDTIC.com/ADI...

  • Page 60: Specifications

    Center pin +7V@2 amps Outer ring Board Current Measurements The ADSP-21161N EZ-KIT Lite board provides two zero-ohm resistors that can be removed to measure current draw. Table 2-15 shows the resis- tor number, the voltage plane, and a short description of the plane components.
  • Page 61 74LVC00AD PHILIPS 74LVC00AD SOIC14 12.288MHZ DIGI-KEY SGR-8002DC-PCC-ND OSC001 12.288M 25MHZ DIGI-KEY SGR-8002DC-PCC-ND OSC001 CS8416-CS CIRRUS LOGIC CS8416-CSZ SOIC28 LMV722M U12-20,U28 NATIONAL LMV722MNOPB SOIC8 SEMI MT48LC8M16A U2-4 MICRON MT48LC8M16A2P-6A 2P-6A TSOP54 74FCT244AT IDT74FCT244CTQG QSOP20 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 62 MQFP52 DEVICES ADG774ABRQZ ANALOG ADG774ABRQZ QSOP16 DEVICES ADP1864 ANALOG ADP1864AUJZ-R7 SOT23-6 DEVICES RUBBER FOOT M1-5 MOUSER 517-SJ-5018BK SWITCH- RAPC712X 2.5MM_JACK CRAFT CON005 TORX173 6PIN TOSHIBA TORX173(F) CON008 RCA 4X2 SWITCH- PJRAS4X2U01X CON011 CRAFT ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...

  • Page 63: Adsp-21161N Ez-Kit Lite Bill Of Materials

    ADSP-21161N EZ-KIT Lite Bill Of Materials Ref. Qty. Description Reference Manufacturer Part Number Designator RCA 1X1 SWITCH- PJRAN1X1U01X CON012 CRAFT RCA 2X2 SWITCH- PJRAS2X2S01X CON013 CRAFT LNKPRT 12X2 P13-14 HONDA(TSUS RMCA-EA26LMY-0M03-A+ CON010 HINK) .05 10X2 TYCO 5-104069-1 CON014 MOMENTARY SW1-8...
  • Page 64 C204 0.22UF 25V 10% C156-164,C172, 08053C224FAT 0805 C183 0.1UF 50V 10% C1,C7,C9-11, 08055C104KAT 0805 C33,C87-88, C90,C137,C139, C150-151,C173, C182,C191-192 1000PF 50V 5% C3,C14-15,C19- 08055A102JAT2A 0805 20,C24-25,C29- 30,C181 10UF 16V CT19-20,CT22, TAJC106K016R 10% C CT36 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 65 ADSP-21161N EZ-KIT Lite Bill Of Materials Ref. Qty. Description Reference Manufacturer Part Number Designator 10K 1/10W 5% R3,R5,R7,R13, VISHAY CRCW080510K0JNEA 0805 R18-20,R124, R126,R128, R130,R132, R134,R136, R144-146,R148- 149,R151,R158- 164,R172,R175, R190,R219-220 33 1/10W 5% R1,R8,R150, VISHAY CRCW080533R0JNEA 0805 R152 680 1/10W 5%...
  • Page 66 120PF 50V 5% C13,C18,C23, 12065A121JAT2A 1206 C28,C187-190 75 1/8W 5% VISHAY CRCW120675R0JNEA 1206 820PF 100V C32,C34 12061A821KAT2A 10% 1206 47.0K 1/10W VISHAY CRCW080547K0FKEA 1% 0805 680PF 50V 1% C37,C43,C49, 08055A681FAT2A 0805 C55,C61,C67, C73,C79 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 67 ADSP-21161N EZ-KIT Lite Bill Of Materials Ref. Qty. Description Reference Manufacturer Part Number Designator 10UF 25V PANASONIC ECJ4YF1E106Z +80-20% 1210 2.74K 1/8W 1% R63,R71,R79, VISHAY CRCW12062K74FKEA 1206 R87,R95,R103, R111,R119 5.49K 1/8W 1% R60-61,R68-69, VISHAY CRCW12065K49FKEA 1206 R76-77,R84-85, R92-93, R100-101,R108- 109,R116-117 3.32K 1/8W 1%...
  • Page 68 C85-86 12065A102JAT2A 1206 2200PF 50V 5% C40,C46,C52, 12065A222JAT050 1206 C58,C64,C70, C76,C82 100K 1/8W 5% R167 VISHAY CRCW1206100KFKEA 1206 604.0 1/8W 1% R65,R73,R81, PANASONIC ERJ-8ENF6040V 1206 R89,R97,R105, R113,R121 1UF 20V 20% A CT12-18 TAJA105K020R ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 69 ADSP-21161N EZ-KIT Lite Bill Of Materials Ref. Qty. Description Reference Manufacturer Part Number Designator 4.7UF 25V CT23-25 TAJC475K025R 10% C 20.0K 1/8W 1% R170,R173 VISHAY CRCW120620K0FKEA 1206 255.0K 1/10W R171 VISHAY CRCW06032553FK 1% 0603 80.6K 1/10W R166 DIGI-KEY 311-80.6KHRCT-ND 1% 0603 6.8UH 25%...
  • Page 70 A-10 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 71 ADSP-21161 EZ-KIT LITE Schematic ANALOG 20 Cotton Road Nashua, NH 03063 DEVICES PH: 1-800-ANALOGD ADSP-21161 EZ-KIT LITE Title TITLE Size Board No. A0157-2000 www.BDTIC.com/ADI Date 11-8-2006_10:31 Sheet...
  • Page 72 3.3V 3.3V A[0:21] D[16:47] ADDR0 DATA16 L0ACK L0ACK SCLK0 SCLK0 ADDR1 DATA17 L0CLK L0CLK SFS0 SFS0 ADDR2 DATA18 L0D0 L0D[0:7] L0DAT0 SD0A SD0A R155 R156 R157 ADDR3 DATA19 IRQ2 L0D1 L0DAT1 SD0B 0805 0805 0805 ADDR4 DATA20 L0D2 L0DAT2 ADDR5 DATA21 L0D3 L0DAT3...

  • Page 73: Memory

    A[0:14] SDRAM D[16:47] D[16:47] 128Mb (2M X 16 x 4 Banks) L0D0 L0D[0:7] L0D1 L0D2 L0D3 L0D4 L0D5 L0D6 L0D7 L1D0 L1D[0:7] L1D1 L1D2 SDA10 DQ10 SDA10 DQ10 SDA10 DQ10 L1D3 DQ11 DQ11 DQ11 L1D4 DQ12 DQ12 DQ12 L1D5 DQ13 DQ13 DQ13 L1D6...

  • Page 74: Spdif Receiver

    MCLK SOURCE FOR AD1836 AND AD1852 3.3V INSTALL JUMPER ON 1 & 2 TO USE AUDIO OSCILALTOR INSTALL JUMPER ON 2 & 3 TO USE CS8416 MCK AUDIO_OSC SHORTING 47.0K JUMPER MCLK 0805 0805 DEFAULT=1&2 S/PDIF RX SPDIF_MCK IDC3X1 OSCLK DBCLK C193 0.01UF...

  • Page 75: Audio Codec

    INSTALL JUMPER JP4, REMOVE JP1, JP23 AND JP26 TO CONNECT CODEC TO SPI PORT REMOVE JUMPER JP1, JP4 AND JP26 TO USE FLAG0 FOR PUSH BUTTON OR EXPANSION HEADER ODVDD IS CONNECTED TO 3.3V 3.3V 3.3V SD0A ASDATA1 OUT1L+ OUT1L+ DAC1 LEFT ASDATA2 ASDATA2...

  • Page 76: Audio

    CON013 FER3 10UF 5.76K 5.76K CAP002 1206 1206 1206 LOOP_ADC1_LEFT 120PF 100PF 1206 1206 237.0 AGND 1206 IN1L- AGND VREF LMV722M SOIC8 1000PF 0805 5.76K 5.76K 1206 1206 100PF 1206 ADC1 LEFT C187 120PF 1206 AGND 1000PF 750.0K 0805 1206 237.0 1206 IN1L+...
  • Page 77 SHORTING JUMPER DEFAULT=1&3 CON013 FER5 10UF 5.76K 5.76K SHORTING CAP002 1206 1206 1206 JUMPER DEFAULT=2&4 LOOP_ADC2_LEFT ADC2 LEFT INPUT MODE 120PF 100PF 1206 1206 PGA MODE 3-5 & 4-6 HIGH PERFORMANCEMODE 1-3 & 2-4 IN2L2 IN2L- AGND AGND 237.0 1206 VREF LMV722M SOIC8...

  • Page 78: Audio In Mic/Line, Headphone Out

    MIC PRE AMP GAIN SJ12 1&2 20dB SHORTING 2&3 40dB JUMPER NONE 0 dB DEFAULT=NOT INSTALLED IDC3X1 1.0K 100.0 1206 1206 820PF 1206 10.0K 1206 AVCC SJ13 SHORTING FER7 JUMPER 10UF DEFAULT=3&5 CAP002 1206 SJ14 LMV722M SHORTING SOIC8 JUMPER DEFAULT=4&6 10.0K 1206 2.0K...

  • Page 79: Audio Out 1

    DAC1_LEFT 5.49K 100PF 1206 1206 11.0K 3.32K 1206 1206 OUT1L- CT26 330PF CON011 68UF 0805 604.0 CAP003 1206 DAC1 LEFT 100PF LOOP_DAC1_LEFT 1206 LMV722M 680PF SOIC8 0805 5.49K 1.65K 2200PF 49.9K 1206 1206 1206 1206 OUT1L+ 2.74K 220PF 1206 1206 AGND VREF AGND...

  • Page 80: Audio Out 2

    5.49K 100PF 1206 1206 11.0K 3.32K 1206 1206 OUT2L- CT28 330PF CON011 68UF 0805 604.0 CAP003 1206 DAC2 LEFT 100PF LOOP_DAC2_LEFT 1206 LMV722M 680PF SOIC8 0805 5.49K 1.65K 2200PF 49.9K 1206 1206 1206 1206 OUT2L+ 2.74K 220PF 1206 1206 AGND VREF AGND 5.49K...

  • Page 81: Audio Out 3

    5.49K 100PF 1206 1206 11.0K 3.32K 1206 1206 OUT3L- CT30 330PF CON011 68UF 0805 604.0 CAP003 1206 DAC3 LEFT 100PF LOOP_DAC3_LEFT 1206 LMV722M 680PF SOIC8 0805 5.49K 1.65K 2200PF 49.9K 1206 1206 1206 1206 OUT3L+ 220PF 2.74K 1206 1206 AGND VREF AGND R101...

  • Page 82: Audio Out 4

    R109 5.49K 100PF 1206 1206 R107 R110 11.0K 3.32K 1206 1206 OUT4L- CT32 330PF R113 CON011 68UF 0805 604.0 CAP003 1206 DAC4 LEFT 100PF LOOP_DAC4_LEFT 1206 LMV722M 680PF SOIC8 R108 0805 R112 R114 5.49K 1.65K 2200PF 49.9K 1206 1206 1206 1206 OUT4L+ R111...

  • Page 83: Pushbuttons

    3.3V 3.3V R124 R130 EXFLAG0 EXFLAG3 0805 0805 R123 R129 0805 JP26 0805 FLAG0 FLAG3 IDC2X1 74LVC14A 74LVC14A SWT013 SWT013 SOIC14 MOMENTARY CT12 MOMENTARY CT15 SOIC14 SJ16 SHORTING JUMPER DEFAULT=1 & 2 3.3V 3.3V 3.3V R126 R132 R136 EXFLAG1 EXIRQ0 EXIRQ2 0805 0805...

  • Page 84: Leds, Reset, And Oscillators

    3.3V RESET LED1 LED001 R143 LED11 POWER GREEN 0805 LED001 RESET R147 FLAG4 0805 FLAG[4:9] FLAG5 FLAG6 FLAG7 FLAG8 FLAG9 3.3V LED2 LED3 LED4 LED5 LED6 LED7 C167 YELLOW YELLOW YELLOW YELLOW YELLOW YELLOW 0.01UF LED001 LED001 LED001 LED001 LED001 LED001 0805 74FCT244AT...
  • Page 85 A[8:0] VCC 3.3V 1.8V EBOOT TIMEXP LBOOT EXIRQ2 DMAG1 MISO DMAR1 EXFLAG0 MOSI DMAG2 EXFLAG1 SPIDS DMAR2 EXFLAG2 SPICLK EXFLAG3 D[23:16] SBTS IDC5X1 EXIRQ0 RESET IDC6X2 EXIRQ1 REDY CON023 BMSTR BRST CON022 All USB interface circuitry is considered proprietary and has been omitted from this schematic.
  • Page 86 FER13 2.5A FUS001 FER002 DO-214AA V_UNREG INPUT OUTPUT ADP3339AKCZ-5 SOT-223 R167 CT19 CT20 1000PF 100K 10UF 0.1UF 10UF 0.1UF DO-214AA 1206 1206 0805 0805 7_0V_POWER CON005 FER9 SHGND SHGND SHGND SHGND 1206 1000PF 1206 AGND FER10 RUBBER FOOT RUBBER FOOT RUBBER FOOT RUBBER FOOT RUBBER FOOT...

  • Page 87: Connectors

    P10 (host processor), 1-10, 1-11, 2-4, 2-19 audio P11 (voltage), 2-19 connectors (J2-6, P4), 2-18 P12 (SPORT1, SPORT3), 2-19 input channels, 1-11, P13-14 (link port), 2-20 interface, 1-11, P16 (power), 1-5, 2-20 output jacks, 1-12, ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 88 1-13 push buttons (SW5-7), 1-11 expansion connectors (un-installed), request pins (IRQ0-2), 1-11, 2-16 external data bus, interrupts, 1-10 JTAG memory, 1-8, connector (ZP4), 2-21 external ports emulation port, clock ratios, connector (P9), 2-18 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 89 See FLAGx, SWx boot mode, push buttons connectors (P13-14), 2-20 See also switches by name (SWx), 2-13 link ports diagram of locations, 2-13 disable jumper (P17), processor ID settings, 2-12 RCA jacks, 1-12, 2-4, 2-18 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
  • Page 90 MCLK source, specifications, of this EZ-KIT Lite, 2-22 SPORT0, VERF flag (LED9), 1-12, 2-14 SPORT1 VisualDSP++ connections, 2-11 documentation, connector (P12), 2-19 environment, SPORT2, voltage regulators, xiii, 2-22 SPORT3 connections, connector (P12), 2-19 ADSP-21161N EZ-KIT Lite Evaluation System Manual www.BDTIC.com/ADI...
